UM1743Demonstration functional description (STM324x9I-EVAL, STM324xG-EVAL, STM32F429I-
8.1.1

CPU usage

The CPU usage utility provides a graphical representation of the CPU usage evolution
(Figure 40) during the demonstration run time starting for the first time it was launched. Note
that once launched the CPU usage utilities keep running in background and can be restored
in any time.
8.1.2

Kernel log

The kernel log utility gathers all the kernel and module messages and saves them into a
dedicated internal buffer. The Log messages can be visualized at any time during the
demonstration run time, as shown in

Figure 40. CPU usage

Figure 41.

Figure 41. Example of Log messages

DocID026161 Rev 4 53/111
110
