UM1743Demonstration functional description (STM324x9I-EVAL, STM324xG-EVAL, STM32F429I-
Data structure used
USBDSettingsTypeDef
Functional description
Run USB Device demonstration by clicking USB device icon in the main desktop, as in
Figure 60.
Button
Connect USB
Disconnect USB

Table 22. Data structure for USBD module

Structure
sd_mounted: connection status

Figure 60. USBD module startup

Table 23. USBD module controls

Preview
DocID026161 Rev 4
Description
Description
Changes the USB logo as follows:
Changes the USBD status as CONNECTED
Changes the USB logo as follows:
Changes the USBD status as DISCONNECTED
71/111
