JMA MULTICODE Manual page 20

3.3.2.2 FEELER 1P
The 1P feeler is used to adjust the reader and to code the point or channel keys.
To adjust the reader:
1) Remove the lever (T8) and let it drop to its position.
2) Position the RPC adjustment sheet in the clamp.
3) Go to the SETTINGS menu, select settings adjust zero-machines (safety key) Reader.
4) Select the jaw and then press the cutter adjustment button.
5) After having performed the cycle, return the feeler to its rest position.
To code point or channel keys
1) Remove the lever (T8) and let it drop to its position.
2) In the technical specification of the key, press the key reading button.
20
T8 T8
FIG. 25
FIG. 26
