JMA NOMAD GO User Manual

JMA NOMAD GO User Manual

Key cutting machine
Hide thumbs Also See for NOMAD GO:

Advertisement

Quick Links

Download this manual
19 19
EN
NOMAD GO
Key Cutting Machine User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the NOMAD GO and is the answer not in the manual?

Questions and answers

Related Manuals for JMA NOMAD GO

Summary of Contents for JMA NOMAD GO

  • Page 1 19 19 NOMAD GO Key Cutting Machine User Manual...

  • Page 2: Table Of Contents

    IMPORTANT Due to the safety regulations governing air and maritime transport, the machine battery comes separate. Follow the steps below to connect it: Before proceeding, make sure that the on/off switch (11) and the master switch (15) are OFF. 1) Turn the machine onto its back. Remove the three screws (O) and the four feet (Q) to take off the protective screen.

  • Page 3: Introduction And General Overview

    The machine must always be transported in its original packaging to ensure its physical integrity. 1.1 OVERVIEW The NOMAD GO key cutting machine has been designed to meet European Regulations (EC). 1.3 IDENTIFICATION LABEL Solutions have been applied to the design that seek to...
  • Page 4 NOMAD GO KEY CUTTING MACHINE This manual provides information that the operator should be aware of and that will enable safe use of the machine.

  • Page 5: Safety Measures

    On wet floors, users should wear safety shoes with a non-slip sole. The NOMAD GO key cutting machine and its safety devices are compliant with Directive 2006/42 EC on Machinery. - SAFETY GOGGLES: The operator should wear safety gog- gles over the eyes during the duplication stages of operation.

  • Page 6: Residual Risks

    2.3 RESIDUAL RISKS MECHANICAL RISK The NOMAD GO key cutting machine has been designed The machine is fitted with tools (cutter and with the utmost care to ensure it is safe during transport, tracer) that are necessary for key dupli- adjustment, duplication and maintenance.

  • Page 7: Installation And Preparation Of The Machine

    1) Very carefully roll the machine onto its rear side. TION 2) Attach the tool (E) to the machine using the two screws - The NOMAD GO key cutting machine has been designed (U) included with the accessories. for use in commercial and light industrial environments (e.g.

  • Page 8: Characteristics Of The Machine

    NOMAD GO KEY CUTTING MACHINE 4. MACHINE CHARACTERISTICS The NOMAD GO machine is a small but highly precise cut- The machine is fitted with two ergonomically ting machine for copying flat cylinder lock keys, vehicle keys, designed levers. The operator MUST hold the star keys and special keys.

  • Page 9: Components And Functional Parts

    MACHINE CHARACTERISTICS Carriage range (maximum rail length): 53 mm Dimensions: TEST TEST Width: 266 mm; Height: 260 mm; Depth: 165 mm Weight: 8 kg 100% 100% 4.4 COMPONENTS AND FUNCTIONAL PARTS 4.4.1 Accessories To recharge the battery, just connect the power adapter su- pplied with the machine to a 220-110 V power supply and the 1 - Keys for lateral and depth adjustment Jack connector (14) located on the rear of the machine.

  • Page 10: Operation And Functions

    NOMAD GO KEY CUTTING MACHINE 5. OPERATION AND FUNCTIONS 5.1 DEPTH ADJUSTMENT Switch off the power switch (11), switch off the See Figure 5 master switch (15), close the protective screen (16) and check that the machine is NOT connected to Switch off the power switch (11), switch off the the battery charger.
  • Page 11 OPERATION AND FUNCTIONS - Switch off the machine so the cutter stops rotating. - Release the keys from the clamps. - If the duplication process produced any burrs on the copy, these can be removed using the brush that is provided with the machine for this purpose.

  • Page 12: Maintenance

    KEY CUTTING MACHINE 6. MAINTENANCE 6.1 BRUSH REPLACEMENT The NOMAD GO key cutting machine requires no particular maintenance plan. Nonetheless, certain parts should be The brush should be replaced when it can no longer remove checked regularly and eventually replaced once they beco- burrs.

  • Page 13: Tracer Replacement

    MAINTENANCE 6.5 ACCESSING THE LOWER HOUSING See Figure 13 For maintenance requiring access to the lower part of the machine, proceed as follows: 6.3 TRACER REPLACEMENT Switch off the power switch (11), switch off the master switch (15), close the protective screen (16) The tracer should be replaced when it becomes worn.

  • Page 14: Replacing The Jack Connector

    NOMAD GO KEY CUTTING MACHINE down the position of each one for subsequent reconnection. in reverse order. 4) Remove the four screws (T2) holding the electronic card in the machine. See Figure 21 5) Install the new electronic card by securing it with the four screws (T2).

  • Page 15: Replacing The Motor

    WASTE DISPOSAL 5) Move the motor (N) so the two wheels move closer toge- ther. 6) Remove the old belt. Remove it by moving it around the brush. 7) Fit the new belt and visually check it is in the right place. 8) TIGHTENING THE BELT: By turning the tensioning screw (Z), the motor (N) will move towards the bottom of the machine and the belt will consequently become more tense.

  • Page 16: Waste Disposal

    NOMAD GO KEY CUTTING MACHINE 7. WASTE DISPOSAL Waste disposal should be managed according to the legisla- lity of their selective collection systems so that the owners tion in force in the user’s country. of the machine and the distributors may deliver any waste produced within its territory to the collection facility for free.
