3.2.3 CLAMP MODEL

The jaw has two standard clamps, a fixed one (A) and a mobile one (B). One of the important characteristics of the
clamps is that they have two sides to attach different models of keys. Both the fixed clamp and the mobile one, have
two sides, 1 and 2.
The following steps are to change the clamp or the side of the clamp:
1) Unscrew the knob (T3) to the end
2) Push the clamp(s) with your fingers from its rear part removing it towards the operator. (Fig. 20)
3) Clean the clamp housing area with the brush.
4) Change the clamp of the side and fully introduce it.
Note: The information about the clamps to be used appears in the JMAKeyPro software in the tablet.
FIG. 20
