uniquegardendecor.com
(866)
866) 382-8600
6
PK140 pump (1)
Approx. 15" length of ½" black non-kink tubing (1)
Approx. 2" length of 5/8" clear vinyl tubing (1)
# 10 compression stopper (1)
4mm Allen wrench (1)
Wedges (6)
Hose clamps (3)
Note – Hose clamps may be used as flow restrictor
FT- 279 Charente Fountain
COMPONENTS AND PARTS LIST
FT-279B
18.25" x 5.75" H
28 Lbs
FT-279C
8.75" x 12" H
27 Lbs
FT-279E
28.75" x 9.5" H
95 Lbs
FT-279F
12.5" x 23.75" H
146 Lbs
NOTE: Component photos are not to scale
Pump Kit Parts List
(6 pieces)
FT-279A
5" x 14.5" H
12 Lbs
FT-279B
18" x 5.75" H
28 Lbs
FT-279D
5.5" x 1.75" x 4.5" H
3 Lbs
Tools you will need
Level
4mm Allen wrench (included)
This fountain uses cover FTNCOV-LG
Revised October 29, 2015
Fountain holds approximately
10 gallons of water
Advertisement
Related Manuals for YARDART Charente FT-279
Summary of Contents for YARDART Charente FT-279
- Page 1 FT- 279 Charente Fountain (6 pieces) Revised October 29, 2015 COMPONENTS AND PARTS LIST uniquegardendecor.com (866) 866) 382-8600 FT-279A 5” x 14.5” H 12 Lbs FT-279B FT-279B 18.25” x 5.75” H 18” x 5.75” H 28 Lbs 28 Lbs FT-279C 8.75”...
- Page 2 FT- 279 Charente Fountain (6 pieces) Revised October 29, 2015 ASSEMBLY INSTRUCTIONS 1. Make sure you are assembling your fountain on a level surface capable of holding a minimum of 400 pounds with approximately a 1.75 square foot Fig A footprint.
