Pump Kit Parts List
PK120 pump (1)
Approx. 6" length of ½" black non- kink tubing (1)
#7 compression stopper (1)
wedges (2)
Hose clamps (3)
4mm Allen wrench (1)
Note – Hose clamps may be used as flow restrictor
FT-53 Medici Elipse Fountain
(5 pieces)
COMPONENTS AND PARTS LIST
FT-53BC
4"W x 3"H
2 lbs
Non kink tubing
P-630
37"L x 31"W x 15.5"H
166 lbs
PD-195A
16"W x 14.5"H
152 lbs
PD-195B
19"W x 3.5"H
56 lbs
uniquegardendecor.com
(866) 382-8600
Tools you will need
Level
4mm Allen wrench (included)
This fountain uses cover FTNCOV-SM
Revised May 24, 2012
