uniquegardendecor.com
(866) 382-8600
FT-29B
12"w x 12"h
65 lbs
FT-29B/30C
12"w x 8"h
52 lbs
PK800 pump (1)
Approx. 6" length of ¾" clear tubing (1)
approx. 18" length of ½" black non-kink tubing (1)
approx. 6" length of ½" black non-kink tubing (7)
large T connector ½"x¾"x ½: (1)
4mm Allen wrench (1)
Note – Hose clamps may be used as flow restrictor
FT-29 Palazzo Obelisk Fountain
(5 pieces)
COMPONENTS AND PARTS LIST
FT-29A
11"w x 38" h
175 lbs
Pump Kit Parts List
Level
FT-29BB/30CC
4mm allen wrench (included)
5"w x 5"h
4 lbs
FT-29C/30D
45"w x 11"h
579 lbs
½"x½"x½" T connector (3)
#7 compression stopper (1)
wedges (4)
Hose Clamps (6)
Revised May 24, 2012
Tools you will need
This fountain uses cover
FTNCOV-XLG
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for YARDART Palazzo FT-29
Summary of Contents for YARDART Palazzo FT-29
- Page 1 FT-29 Palazzo Obelisk Fountain (5 pieces) Revised May 24, 2012 COMPONENTS AND PARTS LIST uniquegardendecor.com (866) 382-8600 FT-29A 11”w x 38” h 175 lbs FT-29B 12”w x 12”h 65 lbs FT-29B/30C Tools you will need 12”w x 8”h 52 lbs Level FT-29BB/30CC 4mm allen wrench (included)
- Page 2 FT-29 Palazzo Obelisk Fountain (5 pieces) Revised May 24, 2012 ASSEMBLY AND GENERAL FOUNTAIN INSTRUCTIONS Bottom of Obelisk assembly 18” length of Non- 6” lengths of Non- kink tubing kink tubing to each side spitter Small “T” connectors Large “T” connector 6”...
- Page 3 FT-29 Palazzo Obelisk Fountain (5 pieces) Revised May 24, 2012 ASSEMBLY AND GENERAL FOUNTAIN INSTRUCTIONS 1. Make sure you are assembling your fountain on a level surface. 2. Place the Basin (FT-29C/30D) into position where the fountain will be installed. 3.
