Energy Efficiency
Input 100-240VAC 50-60Hz
Output: 12VDC 1.5A (18W);
Operation: 0°Cto 50°C
Environmental
Storage: -30°C to 60°C
Humidity: 10% to 90% Non-condensing
● Unit Dimension: 95mm(L)x95mm(W)x193mm(H)
● Unit Weight: 690g
Physical
● Entire Package Dimension: 286mm(L)x126.5mm(W)x105mm(H)
● Entire Package Weight: 960g
● GWN7062 Router
● Universal Power Supply
Package Content
● Network Cable
● Quick Installation Guide
Compliance
FCC, CE, RCM, IC, UKCA
INSTALLATION
Before deploying and configuring the GWN70xx router, the device needs to be properly powered up and connected to the
network. This section describes detailed information on the installation, connection, and warranty policy of the GWN70xx
router.
Package Contents
○ GWN7052/GWN7052F
○ GWN7062
Table 2: GWN7062 Technical Specifications
Figure 1: GWN7052/GWN7052F Package Contents
