Alerts
Top Access Devices
Top SSIDs
Top Clients
In addition the user can click on the magnifier icon

ROUTER CONFIGURATION

This section includes configuration pages for network WAN ports, LAN ports and shows also the router status.

System Info

System Info displays Device Status to check MAC address, Part Number, Firmware related information, and Uptime for the
GWN70xx and WAN Status showing general information about WAN Port such as IP address and Connection Type.
The router's System Info can be accessed from the Web GUI → Overview → System Info Tab.
Shows Alerts General, Important or Emergency with details and time.
Shows the Top Access Devices list, assort the list by number of clients connected to each access device
including the GWN7052 or data usage combining upload and download. Click on the arrow to go to access
Devices page for basic and advanced configuration options.
Shows the Top SSIDs list, users may assort the list by number of clients connected to each SSID or data usage
combining upload and download. Users may click on to go to SSID page for more options.
Shows the Top Clients list, users may assort the list of clients by their upload or download. Users may click on
to go to Clients page for more options.
Table 4: Overview
Figure 21: LED status
to check the LED status of the router.
