Grandstream Networks GWN70 Series User Manual page 31

● AES/TKIP: use both Temporal Key Integrity Protocol and Advanced Encryption Standard for encryption,
WPA Shared Key Set the access key for the clients, and the input range should be: 8-63 ASCII characters or 8-64 hex characters.
RADIUS Server Configures RADIUS authentication server address.
Address Note: This field is available only when "WPA Key Mode" is set to "802.1x".
Configures RADIUS Server Listening port. Default is: 1812.
RADIUS Server Port
Note: This field is available only when "WPA Key Mode" is set to "802.1x".
Enter the secret password for client authentication with RADIUS server.
RADIUS Server Secret
Note: This field is available only when "WPA Key Mode" is set to "802.1x".
Check the box to enable settings a secondary RADIUS server.
Then you need to specify below three fields:
● RADIUS Server Address: Enter the secondary RADIUS server address.
Secondary RADIUS
● RADIUS Server Port: Enter the secondary RADIUS server port. The default port is 1812 and the range is
Server
● RADIUS Server Secret: Enter the secret password for client authentication with the secondary RADIUS
RADIUS Accounting Configures the address for the RADIUS accounting server.
Server Address Note: This field is available only when "WPA Key Mode" is set to "802.1x".
RADIUS Accounting Configures RADIUS accounting server listening port. Default is 1813.
Server Port Note: This field is available only when "WPA Key Mode" is set to "802.1x".
RADIUS Accounting Enter the secret password for client authentication with RADIUS accounting server.
Server Secret Note: This field is available only when "WPA Key Mode" is set to "802.1x".
Check the box to enable settings a secondary RADIUS accounting server.
Then you need to specify below three fields:
● RADIUS Accounting Server Address: Enter the secondary Accounting RADIUS server address.
Secondary RADIUS
● RADIUS Accounting Server Port: Configures the secondary RADIUS accounting server listening port.
Accounting Server
● RADIUS Accounting Server Secret: Enter the secret password for client authentication with the secondary
Enter the RADIUS NAS ID.
RADIUS NAS ID
Note: This field is available only when "WPA Key Mode" is set to "802.1x".
Enable Captive Portal Click on the checkbox to enable the captive portal feature.
Click Add Blocklist and select from the available devices or add manually the device or selected from
Blocklist Filtering
previously created blocklist.
Client Isolation Client isolation feature blocks any TCP/IP connection between connected clients to GWN76XX's Wi-Fi access
point.
Client isolation can be helpful to increase security for Guest networks/Public Wi-Fi.
Three modes are available:
● Internet Mode: Wireless clients will be allowed to access only the internet services and they cannot access
● Gateway MAC Mode: Wireless clients can only communicate with the gateway, the communication
this provides the most reliable security.
1-65535.
server.
Default is 1813.
RADIUS accounting server.
any of the management services, either on the router nor the access points GWN76XX.
between clients is blocked and they cannot access any of the management services on the GWN76XX
access points.
