Model assembly

Main Wing Installation
1.Align and insert the wing spar into the wing tubes, then
slide the wing spar into the fuselage.
Note: The connectors on both sides should be attached
precisely and firmly.
2.Secure both wings to the fuselage using the included
screws.
Horizontal stabilizer installation
1.Connect the elevator servo connectors to the servo exten-
sions in the fuselage.
2.Carefully apply foam-safe CA to the base and side of the
horizontal stabilizer slot. Insert the horizontal stabilizers until
they are properly in place.
Required Adhesives:
Foam Safe Medium CA
