7.2 Electronic Controller Module BLE Setting:
SETTING
K1-DIR
BLE
K1-CAL
VER
Press and hold
simultaneously to enter /
exit the menu, click
to turn pages, click REC
button to enter options.
8. Other Operations
① LED: The indicator shows
BLUE → YELLOW → PINK → WHITE → OFF.
② K1-DIR: Positive and negative rotation switching
of the motor controlled by the Wireless
Handwheel Controller.
③ SCREEN: Screen inversion display.
④ VER: Version information.

Specifications

Wireless
Handwheel
Controller
Wireless
Follow
Focus
Controller
Kit
12
SETTING
Scan...
+ Click REC button to
start BLE scanning
/
RED → GREEN →
Screen Size
Battery Specification
Full Battery Life
Input Voltage
Operating Current
Channels
Maximum Transmission Distance
Communication Frequency
Screen Size
Applicable Battery Types
Input Voltage
Full Charge Duration
Output Power
Full Battery Life
Loading Range
Side Power Display
SETTING
Connect
Scanning connection
is successful, and
camera confirms
matching
SETTING
LED
K1-DIR
BLE
SCREEN
K1-CAL
VER
OLED 0.96"
3.7V / 1400mAh / 5.18Wh
20h (without light display status)
5V ~ 12V
Approximate 0.14A
F00 ~ F15: 16 in total, 3 motor numbers
≤100m ( Ideal Conditions )
2.4000～2.4835GHz
OLED 0.96"
LP-E6 / LP-E6N
5V ~ 16.8V
Approximate 1h30min
5V 2A 9V 2A
Approximate 40h
≤6kg
20% - Red Light, 60% - Green Light,
100% - Green Light
SETTING
OFF
Click / to
turn off BLE
①
②
③
