Project Timber Hobbyist Building Instructions page 12

13
Front
16
Purlin fixing
Pilot drill holes
before fixing
30mm
Screws
Fix the L-Bracket
on each end of purlin.
14
50mm
Screws
Pilot drill holes
before fixing
17
Fit and fix
the purlins.
30mm
Screws
See
L-bracket
fixing
detail
Fix the door panel
50mm
Screws
Front
Pilot drill holes
before fixing
Purlin fixing
Back
Front
See
L-bracket
fixing
detail
15
Front
50mm
Pilot drill holes
Screws
before fixing
18 Purlin fixing
30mm
Front
Screws
Pilot drill holes
before fixing
Purlin
Front
Panel
Position and fix in
place the purlin to the
wall panels.
