The finding can be summarized as;
The channel output power instability is directly proportional to the CLGC loop gain variation observed.
The channel output power stability depends on the signal characteristics, PA characteristics, and the CLGC sampling period.
•
As a good starting point, the customer can perform a statistical analysis of the signal, and can use the averaging period with
•
least standard deviation from the expected frame power level as the CLGC sampling period, which ensures good statistical
•
probability of engaging sub-carriers across frequencies.
