ADI_ADRV9025_CLGC_HI_LIMIT
_TX_ATTEN
ADI_ADRV9025_CLGC_USER_C
HANGE_LOOP_GAIN
ADI_ADRV9025_CLGC_USER_C
HANGE_TX_ATTEN
ADI_ADRV9025_CLGC_MAX_LI
MIT_NUM_BATCHES
ADI_ADRV9025_CLGC_ASSERT_
PA_PROTECTION

CLGC CAPTURE ERRORS

Table 43. CLGC Capture Errors
ClgcState Error Enum
ADI_ADRV9025_CLGC_CAP_START_FUNC_ORX_ERR
The minimum Tx attenuation can be configured via
adi_adrv9025_ClgcConfigSet( ) API.
1. The absolute value of the upper limit of Tx
attenuation has been reached. Eg: If the maximum
Tx attenuation limit has been configured as 10dB,
and the user requests a loop gain that causes CLGC
to increase the Tx attenuation to a value greater
than 30dB, then the CLGC limits the Tx attenuation
to 30dB in this case and returns this error status.
2.
3. The maximum Tx attenuation can be configured via
adi_adrv9010_ClgcConfigSet( ) API.
An expected loop gain change from the user has been
detected and CLGC will re-initialize.
A Tx attenuation change from the user has been
detected and CLGC will re-initialize
The limit for the maximum no. of batches per CLGC run
has been breached and the CLGC is not able to estimate
the loop gain correctly for it to converge
CLGC algorithm has detected a PA protection assertion
Description
CLGC ORx capture did not
complete successfully
Rev. PrA | Page 72 of 82
Preliminary Technical
such that the loop gain falls within the
range acceptable to the user.
Adjust the Tx attenuation upper
•
limit to increase the range of Tx
attenuation accesible to the CLGC
algorithm
If the absolute maximum value of
•
Tx attenuation is reached, then it
is recommended to adjust the
loop gain such that the loop gain
falls within the range acceptable
to the user.
No action expected from the user
•
If the CLGC does not recover
•
from this state, please examine
the Orx qualifying threshold
No action expected from the user
•
If the CLGC does not recover
•
from this state, please examine
the Tx qualifying threshold
Increase the batch sample time.
The ORx channel has a low SNR that
could be causing this error. Examine
the ORx path.
Decrease Tx attenuation of the
•
signal to recover from a PA
protection error.
Increase the digital back off in the
•
baseband Tx signal
Recommended Recovery Actions
Verify that the ORx channel in
•
question is NOT enabled.
Verify that a valid path exists b/w the
•
Tx channel and ORx channel in
question.
