Summary of Contents for Cookology VER601BK
- Page 1 VER601BK&VER605BK VER701BK&VER705BK VER801BK&VER805BK VER901BK&VER905BK Cooker hood Instruction manual...
-
Page 2: Table Of Contents
CONTENT 1……………………………………….Notice 2…………………………………….Feature& Notice of installation 3………………………………………..Installation 4……………………………………….. Speed adjustment 5………………………………………..Safety Warning 6…………………………………………Maintenance 7………………………………………….. Abnormity and Solution... -
Page 3: Notice
1.Notice This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 4 The instructions shall state the substance of the following: – there shall be adequate ventilation of the room when the range hood is used at the same time as appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into the room);...
- Page 5 – CAUTION: Accessible parts may become hot when used with cooking appliances. The installation instructions shall include the substance of the following: – the air must not be discharged into a flue that is used for exhausting fumes from appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into the room);...
- Page 6 – regulations concerning the discharge of air have to be fulfilled. The installation instructions for range hoods with accessible metallic enclosures of class II construction shall include details that indicate the location and maximum permitted lengths for any fixing or mounting screw or other fixing device that penetrates into the range hood to attach an accessory such as a facia or...
- Page 7 required location of these screws or fixing devices and include the substance of the following warning. Warning: Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards Feature The cooker hood uses high quality materials, and is made with a streamlined design.
-
Page 8: Installation
3. Installation 1.The cooker hood should be placed at a distance of 65-75cm (26-30inch) from the cooking surface for the best effect. See Pic 1. 2. Using a drill bit with an 8mm diameter, make 8 holes in the wall on the position that you preserve for installing the chimney and cooker hood body. - Page 9 8. Put the inner chinmey and outer chinmey together,use self tapping screw ST4*8mm to fix the outter chimney bracket onto the outer chimney.Please make sure that the inner chimney it is adjustable inside the outerchinmey.See pic 5 Pic 5 9. Positioning the outer chinmey on the top of the cooker hood,use self tapping screw ST4*8mm to fixed the chinmey bracket to cookerhood.
-
Page 10: Speed Adjustment
● After the installation, make sure that the cooker hood is level to avoid grease collection at on end. See Pic. 8 4. SPEED ADJUSTMENT For VER601BK , VER701BK, VER801BK, VER901BK 1. Connect to the power supply, the cooker hood enter into standby mode. - Page 11 5. Medium Speed button Press this button to operate at medium speed. 6. High Speed button Press this button to operate at high speed. 7. Light button Press once, the lighting will be on, press again, the lighting will be off.
-
Page 12: Safety Warning
5. Safety Warning In certain circumstances electrical appliances may be a danger hazard. Keep electrical appliances out of reach from Children or infirm persons. Do not let them use the appliances without supervision. This appliance is not intended for use by persons (including children) with reduced physical. -
Page 13: Maintenance
6. MAINTENANCE 1. It is recommended to operate the appliance prior to cooking. 2. It is recommended to leave the appliance in operation for 15 minutes after cooking is terminated in order to completely eliminate cooking vapors and odors. 3. The proper function of the cooker hood is conditioned by the regularity of the maintenance operations, in particular, the active carbon filter. -
Page 14: Abnormity And Solution
Abnormity and Solution Fault Cause Solution The leaf blocked Get rid of the blocking The capacitor damaged Replace capacitor Light on, but motor The motor jammed bearing Replace motor does not work damaged The internal with of motor off or a Replace motor bad smell from the motor Beside the above mentioned, check the following:... - Page 15 ENVIRONMENTAL PROTECTION: This product is marked with the symbol on the selective sorting of waste electronic equipment. This means that this product must not be disposed of with household waste but must be supported by a system of selective collection in accordance with Directive 2002/96/EC.
