ERROR CODE DETAILS

Code 01-01-to 3F-XX

Error Code Item
01-01 Error Message
Outline
Detection Description The printer detected absence of cards in the card case during card print
Remedy
01-02 Error Message
Outline
Detection Description The printer detected absence of cards in the card case during standby.
Remedy
04-01 Error Message
Outline
Detection Description The printer detected the front access cover open.
Remedy
05-01 Error Message
Outline
Detection Description The printer detected the front access cover open during initialization.
Remedy
Service Manual_AVA1_ENG-20220922_I
Description
Feeder empty
Card empty error (during card print reception)
reception.
[Related parts]
Harnesses from the Card Sensor (SN1) to the Main board
•
Card Sensor (SN1)
•
Main board
•
[Remedy]
1. Check if cards are properly loaded in the card case.
2. Check the reaction of the Card Sensor (SN1) in the sensor check mode
of the service mode (page 27).
3. Check/replace the related harness/cable, connector and parts.
Feeder empty
Card empty error (during standby)
[Related parts]
Harnesses from the Card Sensor (SN1) to the Main board
•
Card Sensor (SN1)
•
Main board
•
[Remedy]
1. Check if cards are properly loaded in the card case.
2. Check the reaction of the Card Sensor (SN1) in the sensor check mode
of the service mode (page 27).
3. Check/replace the related harness/cable, connector and parts.
Cover open
Front access cover open error
[Related parts]
Harnesses from the Front Cover Switch (MS1) to the Main board
•
Front Cover Switch (MS1)
•
Main board
•
[Remedy]
1. Close the front access cover.
2. Check the reaction of the Front Cover Switch (MS1) in the sensor
check mode of the service mode (page 27).
3. Check/replace the related harness/cable, connector and parts.
Cover open
Front access cover open error (during initialization)
[Related parts]
Harnesses from the Front Cover Switch (MS1) to the Main board
•
Front Cover Switch (MS1)
•
Main board
•
[Remedy]
1. Close the front access cover.
2. Check the reaction of the Front Cover Switch (MS1) in the sensor
check mode of the service mode (page 27).
3. Check/replace the related harness/cable, connector and parts.
