MODEL US0208 / US0208PL SEMI-ELECTRIC BED
MODEL US0458 / US0458PL FULL-ELECTRIC / LOW BED
USER MANUAL
READ THIS MANUAL BEFORE OPERATING THE PATRIOT HOMECARE BED.
SAVE THIS MANUAL FOR FUTURE USE.
NOTE: THE MOST CURRENT VERSION OF THIS MANUAL
CAN BE FOUND ONLINE AT www.grahamfield.com
US0208-INS-LAB-RevB09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUMEX PATRIOT Homecare Bed Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Graham Field LUMEX PATRIOT Homecare Bed Series

  • Page 1 MODEL US0208 / US0208PL SEMI-ELECTRIC BED MODEL US0458 / US0458PL FULL-ELECTRIC / LOW BED USER MANUAL READ THIS MANUAL BEFORE OPERATING THE PATRIOT HOMECARE BED. SAVE THIS MANUAL FOR FUTURE USE. NOTE: THE MOST CURRENT VERSION OF THIS MANUAL CAN BE FOUND ONLINE AT www.grahamfield.com US0208-INS-LAB-RevB09...
  • Page 2: Table Of Contents

    CONTENTS SAFETY ....................................... 3 WARNING / CAUTION SUMMARY .............................. 3 INTRODUCTION, PATRIOT HOMECARE BED USER MANUAL ....................4 ™ THERMAL MOTOR PROTECTION .............................. 4 GRAVITY-DOWN FEATURE FOR HEAD AND KNEE ELEVATION .................... 4 ASSEMBLY INSTRUCTIONS ................................5 HEAD AND FOOT ASSEMBLY ..............................5 MOTOR ASSEMBLY ..................................
  • Page 3: Safety

    1 SAFETY The safety statements presented in this chapter refer to the basic safety information that the operator of the Patriot Homecare Bed shall pay attention to and abide by. There are additional ™ safety statements in other chapters or sections, which may be the same as or similar to the follow- ing, or specific to the operations.
  • Page 4: Introduction, Patriot Homecare Bed User Manual

    2 INTRODUCTION, PATRIOT HOMECARE BED USER MANUAL ™ This manual contains assembly and maintenance instructions for your Model US0208 / US0208PL Semi-Electric and US0458 / US0458PL Full-Electric / Low Patriot bed. Read the entire manual care- ™ fully before using your bed, and refer to it during use if you have questions. THERMAL MOTOR PROTECTION This product is powered by a quiet, efficient DC motor system.
  • Page 5: Assembly Instructions

    3 ASSEMBLY INSTRUCTIONS HEAD AND FOOT ASSEMBLY hook rivet motor cam foot head section section hook rivet Assembly, head and foot sections Note: Grid deck not shown for clarity 1. Lay the head and foot sections on their sides at approximately right angles to each other with motor cams up, as shown above.
  • Page 6: Motor Assembly

    MOTOR ASSEMBLY WARNING: Assemble motor on bed as follows. While it is possible to Head install the motor backwards, avoid it! Incorrect installation could cause the bed to move in unexpected ways. Note that the motor ends are labeled and embossed with head and foot symbols (shown at right). Ensure that bed head and motor head, and bed foot and motor foot, are matched.
  • Page 7: Install Motor Slide Caps

    pressure Install motor slide caps 7. Position the caps as shown at right so that the grooves in the slide cap are aligned with slide cap the grooves in the motor. 8. Apply straight downward pressure to each end of the cap while sliding into the closed position.
  • Page 8: Bed End Assembly

    BED END ASSEMBLY Full-electric bed only (US0458/US0458PL): Lock motor spring coupling SLIDE IN AND ROTATE TO LOCK ROTATE TO UNLOCK coupler coupler Unlocking Locking coupler coupler gearbox gearbox Before attaching foot end, ensure that hi/lo motor spring coupling is retracted and locked to avoid interference with end gearbox shaft as shown at above right.
  • Page 9: Full-Electric Bed Only (Us0458/Us0458Pl): Align Motor And Gearbox

    7. After bed ends have been attached, install bed end safety pins to act as safety latches. washer (Bed End Safety Pin Kit part number: 690-1000-100; includes bed end four clevis pins, four hitch pins and four washers). A lan- hook yard is supplied to attach hardware to the bed or the end upon disassembly.
  • Page 10: Hi/Lo Rod Assembly / Bed Length

    HI/LO ROD ASSEMBLY / BED LENGTH The hi/lo rod assembly consists of an inner and outer tube with a spring button lock to keep them together. 1. Assemble outer and inner tubes: Semi-electric bed only (US0208/US0208PL): Assemble hi/lo rod Hi/lo rod assembly semi-electric bed US0208 / US0208PL spring button...
  • Page 11: All Models: Attach Hi/Lo Rod To Gearbox Or Motor Shaft Pins

    All models: Attach HI/LO rod to gearbox or motor shaft pins gearbox shaft (or motor shaft) hi/lo rod slot Attach hi/lo rod to gearbox or motor shaft Both ends of the hi/lo rod assembly have a slot to mount on the foot end motor shaft pins and bed end gearbox shaft pins as shown above.
  • Page 12: Bed Operation

    4 BED OPERATION WARNING: Ensure that bed is secure and assembled as instructed on previous pages be- fore operating. Note: In the event of a power failure, use a standard 9V battery to lower the bed's head and foot sections (the 9V battery connection is attached to the motor). When used with the battery, the motor will only lower, not lift, the head and/or foot sections.
  • Page 13: Crank Operation: Semi-Electric Bed Only (Us0208/Us0208Pl)

    CRANK OPERATION: SEMI-ELECTRIC BED ONLY (US0208/US0208PL) Use the crank at the center foot of the semi- foot electric bed (shown at right) to change bed height (raise or lower entire deck). crank Crank operation TRENDELENBURG POSITION, ALL MODELS (HEAD END AT LOWER ELEVATION THAN FOOT END) 1.
  • Page 14: Specifications, All Models

    5 SPECIFICATIONS, ALL MODELS * * Specifications are subject to change without notice. Deck High position height Deck height: High Position US0208/US0208PL: US0458/US0458PL with cast- US0458/US0458PL with 24.0 inches ers in low position: 20.0 inches casters in standard position: 23.5 inches Low position Deck height: Low Position US0208/US0208PL:...
  • Page 15: Accessories: Bed Rails

    6 ACCESSORIES: BED RAILS Patriot Homecare Bed decks are equipped with patent-pending slots specifically for bed rail ™ installation, providing a fixed place to mount GF bed rails. Two styles of Lumex bed rails are de- ® scribed in Section 6: 1) The Patriot Liberty bed rail system, designed specifically for Patriot Beds, and...
  • Page 16: Gf6590B-1: Half No-Gap Head Rail

    GF6590B-1: Half No-Gap Head Rail The Half No-Gap Head Rail, which provides a full head coverage of 31.5 inches, extends to eliminate the gap between the head board and the end of the rail. The GF6590B-1 mount- ed on the bed's head and the GF6580B-1 GF6590B-1 mounted on the bed's foot combine to create Half No-Gap Head Rail...
  • Page 17: Lx5088: No-Gap Bed Rail

    LX5088: No-Gap Bed Rail LX5088 No Gap Side Rail Spring Buttons Spring Buttons Position spring-loaded crossbraces #B into slots G2 and G3 on both sides of bed with spring but- tons facing inward as shown above. GF6580A-1: Low Universal Half Rail Cable tie GF6580A-1 Follow same...
  • Page 18: Service Parts, All Models

    7 SERVICE PARTS, ALL MODELS Service parts for all bed models are shown below and on the following two pages. See pictures and tables for appropriate service parts. Note: To order service parts, contact our Customer Service department at 800-365-2338 (fax 920-929-8213).
  • Page 19: Bed End Components

    BED END COMPONENTS HEAD FOOT Item Part number Description Semi-electric Full-electric US0208 US0208PL US0458 US0458PL 690-7001-901 Head bed end, semi-electric, walnut panels 690-7601-901 Head bed end, semi-electric, plastic panels 690-7004-901 Head bed end, full-electric, walnut panels 690-7604-901 Head bed end, full-electric, plastic panels 690-7001-902 Foot bed end, semi-electric, walnut panels 690-7601-902...
  • Page 20: Bed Service Parts

    BED SERVICE PARTS HEAD FOOT Item Part number Description Semi-electric, H7920SE Full-electric, H7920FE US0208 / US0208PL US0458 / US0458PL 690-2001-913 Motor and pendant, semi-electric 690-2001-411 Pendant, semi-electric 690-2001-410 Motor, semi-electric 690-3001-943 Motor and pendant, full-electric 690-2001-414 Pendant, full-electric 690-3001-415 Motor, full-electric 690-7001-944 Motor and bracket, hi/lo 690-3001-941...
  • Page 21: Maintenance And Safety Checks

    8 MAINTENANCE AND SAFETY CHECKS Perform the following as needed or between patient placements, whichever happens sooner: Electronics and Check all controls to ensure that all functions work Foot control Motors properly. Head control Hi/Lo (if applicable) Check all cables for damaged or frayed wires. Power cord Pendant hand control cord Check to ensure that all plugs are fully inserted or attached.
  • Page 22: Warranty

    9 WARRANTY GF Health Products, Inc. warrants the Patriot US0208 / US0208PL Semi-Electric Homecare Bed ™ Patriot US0458 / US0458PL Full-Electric / Low Bed ™ as follows: ● Two year warranty for defects in workmanship and materials of mechanical components, frame, and electronics.
  • Page 23: Index

    INDEX Assembly instructions 5 Pendant hand control operation, full-electric 12 Pendant hand control operation, semi-electric 12 Power failure; battery operation 12 Bed end assembly 8 Bed end safety pins, install 9 Bed extension kit, 84" 14 Service parts, all models 18 Bed height, low, full-electric 7 Service parts, bed components 18 Bed height, standard, full-electric 7...
  • Page 24 U.S.A. Corporate Headquarters: GF Health Products, Inc. 2935 Northeast Parkway Atlanta, Georgia 30360 telephone: 800-347-5678, 770-447-1609 fax: 800-726-0601, 678-291-3232 www.grahamfield.com...
