- Page 1 LF2020 EASY LIFT SIT-TO-STAND LF2090 BARIATRIC EASY LIFT SIT-TO-STAND USER MANUAL LF2020-INS-LAB-RevD13 © 2013 GF Health Products, Inc. Read this manual before operating your Easy Lift Sit-to-Stand. Save this manual for future use.
-
Page 2: Table Of Contents
CONTENTS 1 INTRODUCTION ..........................3 2 SAFETY PRECAUTIONS ........................ 4 WARNINGS ..........................4 3 FEATURES ............................6 EASY LIFT SIT-TO-STAND FEATURES ................... 6 CONTROL BOX FEATURES ..................... 6 4 HANDLING PROCEDURES ......................7 SHIPPING AND TRANSPORTATION INSTRUCTIONS ............7 5 ASSEMBLY INSTRUCTIONS ......................8 CHARGING THE BATTERIES ....................9 CHECKING BATTERY CAPACITY .................... 9 ALARM BUZZERS . -
Page 3: Introduction
INTRODUCTION Congratulations on your purchase of the Lumex LF2020 Easy Lift Sit-to-Stand (STS) / LF2090 Bariatric Easy Lift Sit-to-Stand (STS). The following pages will provide you with important safety and operating instructions on the use of patient lifts, slings, and accessories, as well as maintenance and warranty information. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS IMPORTANT: Before using patient lift, please read and adhere to the following safety precautions and warnings. Failure to do so could result in serious personal injury or damage to your patient lift. Always consult your healthcare professional to determine safe methods most suitable for your individual abilities. - Page 5 WARNING: GF Health Products, Inc. strongly recommends that two caregivers take part in the lifting process. WARNING: When transferring a patient, always keep the patient centered over the base. WARNING: Ensure that lifting sling loops are correctly attached to the hooks to prevent the patient from sliding or falling out of the sling, which could result in personal injury.
-
Page 6: Features
FEATURES EASY LIFT SIT-TO-STAND FEATURES Pendant Lifting Boom Actuator Knee Pad Control Box Footrest Mast Brake Base CONTROL BOX FEATURES RESET Button Battery Testing Battery Charger Plug-In Pendant Plug-In Actuator Plug-In LF2020-INS-LAB-RevD13... -
Page 7: Handling Procedures
HANDLING PROCEDURES SHIPPING AND TRANSPORTATION INSTRUCTIONS If the patient lift is to be reshipped by common carrier, it should be packed in the same carton in which it was received. Unpacking WARNING: The lift is heavy. To avoid personal injury, DO NOT attempt to remove the lift from the box without assistance. -
Page 8: Assembly Instructions
ASSEMBLY INSTRUCTIONS WARNING: The lift is heavy. To avoid personal injury, DO NOT attempt to assemble the lift without assistance. 1. Remove the nuts and bolts from top and bottom of mast. 2. With one hand on the mast and another on the boom, pull the mast to an upright position. 3. -
Page 9: Charging The Batteries
CHARGING THE BATTERIES Charge the batteries after assembly. 1. Ensure the control box power switch is ON (i.e., the red button is up). 2. Insert the charger plug into the battery box charging socket (the top slot). 3. Insert the other charger plug into the power supply. 4. -
Page 10: Operating Instructions
OPERATING INSTRUCTIONS WARNING: During lifting and lowering, whenever possible, always keep the base legs of the lift in the widest position. WARNING: Use only Lumex slings specially designed for the LF2020 Easy Lift STS / LF2090 Bariatric Easy Lift STS. WARNING: DO NOT use torn, cut, frayed or broken slings as injury could result. -
Page 11: Lifting The Patient
LIFTING THE PATIENT WARNING: Do not attempt to transfer a patient without prior approval of the patient’s healthcare professional and without having read the instructions and practiced using the patient lift. WARNING: Ensure the loor area is clear of any obstacle that could cause a caster to stop and possibly tip the patient lift. - Page 12 Lift and transfer from chair WARNING: GF Health Products, Inc. recommends that two attendants be used when transferring a patient to and from a wheelchair. WARNING: Before transfer, ensure wheelchair wheel locks are in locked position. Wheelchair wheel locks must be in LOCKED POSITION before lowering the patient into the wheelchair, or unexpected wheelchair movement could result, which may result in serious injury to both the patient and the attendants.
-
Page 13: Care And Maintenance
CARE AND MAINTENANCE Proper care and maintenance are essential to keeping your Lumex LF2020 Easy Lift STS / LF2090 Bariatric Easy Lift STS in a safe operating condition. In addition to inspecting the unit before each use, periodic maintenance checks should be done. We further recommend that this unit be serviced at least once annually by a Graham-Field authorized distributor. -
Page 14: Maintenance Schedule
MAINTENANCE SCHEDULE Info: Only qualiied persons should service and repair your Lumex LF2020 Easy Lift STS / LF2090 Bariatric Easy Lift STS. Regular maintenance of your patient lift is necessary to ensure continuing proper and safe operation. Read and observe the following recommended maintenance schedule: Item Inspect... -
Page 15: Troubleshooting
TROUBLESHOOTING The following list of encountered problems and their solutions will assist you in determining what may be causing your Lumex lift not to function as designed. If you have a problem occurring which is not listed below, please contact your distributor or Graham-Field Technical Support for help. Do not attempt to repair components or parts on your lift, as this may invalidate your warranty or cause further problems that may result in patient injury. -
Page 16: Specifications
SPECIFICATIONS Info: All dimensions are given in inches unless otherwise speciied. Base width Open: 43" Closed: 26" Base height clearance 6" Overall base length 50" Lifting height range Minimum: 27" Info: As measured from sling hooks. Maximum: 71" Range: 35" Mast height 50" Maximum weight capacity LF2020 Easy Lift STS: 400 lb, EVENLY DISTRIBUTED LF2090 Bariatric Easy Lift STS: 600 lb, EVENLY DISTRIBUTED Rear locking caster size 4" diameter Front caster size 4” diameter Lifting mechanism 24 DC actuator Battery charger AC 110V / 220V to DC 24V 1 amp LF2020-INS-LAB-RevD13... -
Page 17: 10 Limited Warranty
10 LIMITED WARRANTY GF Health Products Inc. (“Graham-Field”) warrants this product to be free from manufacturing defects in material and workmanship for its period of warranty that is in accordance with industry standards. This warranty is extended only to the original purchaser/consumer or dealer/non-consumer of this new product and to no other purchaser or transferee. - Page 18 THE FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS WARRANTIES AND IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, AND SHALL NOT EXTEND BEYOND THE DURATION OF THE EXPRESS WARRANTY PROVIDED HEREIN, AND THE REMEDY FOR VIOLATIONS OF ANY IMPLIED WARRANTY SHALL BE LIMITED TO THE REPAIR, REPLACEMENT, CREDIT AND/OR REFUND OF THE DEFECTIVE PRODUCT OR PART PURSUANT TO THE TERMS CONTAINED...
-
Page 19: 11 Index
11 INDEX Preparation before lifting 10 Alarm buzzers, signiicance 9 Assembly instructions 8 Safety precautions 4 Safety statements, signiicance of 4 Batteries, charging 9 Shipping and transportation instructions 7 Battery capacity, checking 9 Sit-to-Stand Sling, itting 10 Battery capacity LED indicator lights, signiicance 9 Speciications 16 Before each use 13 Storage 7...
