Page 1 FTM-400XDR/DE Operating Manual 144/430MHz 50W DUAL BAND TRANSCEIVER C4FM/FM Before Using Installation and Connection Basic Operations DG-ID / DP-ID Function Using the Memory Scanning Using the GPS Function Using the APRS Function Using the GM Function Using the WIRES-X Function...
Page 2: Introduction
*Refer to the separate “APRS Operating Manual”  Equipped with GM (Group Monitor) function *Refer to the separate “GM Operating Manual”  Supports Yaesu WIRES-X Internet linking, providing communication with remote partners using the Internet *Refer to the separate “WIRES-X Operating Manual”...
Page 3: Important Precautions For Mobile Radio Operation
Introduction Important precautions for mobile radio operation  The use of protective tape or covering is recommended to protect the wiring and the power cord inside the vehicle.  When installing the unit inside a vehicle, locate the radio, antenna, co-axial cable, etc. at least 20 cm away from the following control equipment.
Page 4: About The Touch Panel
Other company and product names listed in this manual are trademarks and registered trademarks of their respective companies. Unauthorized reproduction or copying of a part or all of the copyrights owned by Yaesu Musen Co., Ltd. in any form whatsoever is strictly prohibited.
Page 5: How To Read This Manual
Introduction How to read this manual In this manual, controller operations are expressed as follows: Press ..........Indicates that the key or switch is to be pressed quickly. Press for 1 second or longer ..Indicates that the key or switch is to be pressed for one second or longer.
Page 6: Table Of Contents
Contents Introduction ..............2 Communicating............49 Features of this radio ..........2 Transmitting ............49 Important precautions for mobile radio operation ..3 Adjusting the transmit power ......50 About the touch panel ..........4 Adjusting the sensitivity of the microphone ..50 About registered trademarks and copyrights ...
Page 7 Contents Using the GPS Function ........87 Using the TOT function ........124 What is GPS? ............87 Changing the Touch Key Function ......125 Positioning Using GPS ..........87 Sending and Receiving Messages and Pictures ..126 Positioning using an external GPS device ..88 Viewing messages and pictures .......
Page 8 Contents Setting the display contrast....... 177 Setting the interval for recording the Switching the time display and the voltage display ... 177 GPS position information ........195 Transmit and receive settings ......178 Data communication settings ......196 Setting the signal format ........178 Setting the COM port ........
Page 9: Before Using
Before Using Safety Precautions (make sure to read these) Make sure to read this manual in order to use this radio safely and correctly. Note beforehand that the company shall not be liable for any damages suffered by the customer or third parties in using this product, or for any failures and faults that occur during the use or misuse of this product, unless otherwise provided for under the law. Type and meaning of the marks This symbol indicates the possibility of death or serious injury being inflicted on the user and the surrounding people when...
Page 10 Safety Precautions (make sure to read these) Do not operate the device when Do not touch any liquid leaking from flammable gas is generated. the liquid display with your bare hands. Doing so may result in fire and explosion. There is a risk of chemical burns occurring when the liquid comes Do not transmit in crowded places into contact with the skin or gets into in consideration of people who are the eyes.
Page 11 Safety Precautions (make sure to read these) Do not use the device when the Refrain from using headphones and power cord and connection cables earphones at a loud volume. are damaged, and when the DC Continuous exposure to loud volumes power connector cannot be plugged may result in hearing impairment. in tightly. Disconnect the power cord Please contact our company amateur and connection cables before customer support or the retail store incorporating items sold separately where you purchased the device as this and replacing the fuse.
Page 12 Safety Precautions (make sure to read these) Keep out of the reach of small Do not place the device on an children. unsteady or sloping surface, or in a location where there is a lot of If not, this may result in injuries to children. vibration. The device may fall over or drop, Do not put heavy objects on top resulting in fire, injury and equipment of the power cord and connection failure.
Page 13: Accessories
Accessories DTMF microphone Bracket for main body Bracket for the MH-48A6JA MMB-36 controller Controller cable DC power cable DC power cable (3 m) (with fuse attached) (with fuse attached) (USA, EXP version) (European version) Spare fuse (15 A) Spare Fuse (15 A) PC connection cable (USA, EXP version) (European version)
Page 14: Name And Function Of Each Component
Name and Function of Each Component Controller Front Ž ‘ Œ ’ “ ” ➀ VOL knob ( The volume will increase when the knob is turned in a clockwise direction and decrease when turned in an counter-clockwise direction. The upper end is for Band A use while the lower end is for Band B use. ➁...
Page 15: Back
Name and Function of Each Component ➆ F/MW key ( Press the button quickly to display the function menu. Press the button for 2 seconds or longer to change to the memory writing mode. ➇ Band B DIAL knob ( • The frequency of the upper band in the dual band display can be adjusted. Press the knob to enable setting the operating band frequency in 1 MHz units.
Page 16: Main Body
➁ MIC jack Plug in the provided microphone cable. ➂ DATA jack Connect MH-85A11U, the optional speaker microphone with camera. * There is no audio output available from the FTM-400XDR/DE to the MH-85A11U speaker. ➃ micro-SD card slot Back Œ...
Page 17: Microphone (Mh-48A6Ja)
Name and Function of Each Component Microphone (MH-48A6JA) [UP] Frequency is increased by 1 step. [DWN] Frequency is decreased by 1 step. [LOCK] Locks / unlocks the [UP] and [DWN] keys and [P1] to [P4] keys. [LAMP] Turns the lamp on the body of the microphone on/off.
Page 18: Explanation Of The Screen
Name and Function of Each Component Explanation of the screen ’ Ž “ ” ‘ Ž ” ‘ Œ Band A display area Band B display area The characters of the name tag and frequency are displayed in white for the operating band, and gray for the sub-band.
Page 19 Name and Function of Each Component z Dual band screen Band A and Band B will be displayed at the top and bottom. [V/M] The VFO channel and memory channel will be switched by touching this symbol. The “V” is displayed in orange in the VFO mode while the “M”...
Page 20 Name and Function of Each Component Change the display mode The display mode will switch in the sequence each time is pressed. Frequency display screen→Compass/Lat&Lon display screen→Altitude display screen*→Timer/Clock screen*→GPS screen* * This screen will be displayed when [DISPLAY]→[1 DISPLAY SELECT] is set to “ON” in the set-up menu. z Compass screen The direction of travel of your own station and direction coordinate of the received station are displayed in the compass screen.
Page 21 Name and Function of Each Component z Altitude display screen The altitude of the current location is shown in the bar graph display. ALTITUDE Displays the current altitude. Vertical axis Represents the altitude. Horizontal axis Represents the distance. [SCALE] When this symbol is touched, the scale of the distance changes. [CLEAR] When this symbol is touched, the graph display will be cleared (erased).
Page 22 Name and Function of Each Component z Lap timer screen [START] The count starts when this symbol is touched. [LAP] The lap time is then saved in the memory (a maximum of 99 lap times can be saved) and displayed in the upper lap display window when this symbol is touched. The lap time (of the new interval) being measured will be displayed in the lower lap display window.
Page 23 Name and Function of Each Component z GPS screen The GPS satellite statuses are shown with numbered icons. 1, 2, etc. Received satellite number Signal strength High Signal strength Medium Signal strength Low Input the character The keyboard screen is displayed when entering a memory channel tag or the call sign of your own station.
Page 24: Installation And Connection
Installation and Connection Installing the Radio Precautions during installation Note the following when installing this radio.  Do not install the radio in a place where there is extreme vibration, where there is a lot of dust, excessive humidity or high temperature, or where it is exposed to direct sunlight.
Page 25: About The Antenna
Installing the Radio About the antenna A good antenna installation is extremely important for transmission and reception purposes. Note the following, as the type and characteristics of the antenna largely determines whether the performance of the radio can be fully realized. • Use an antenna that suits the installation conditions and application objective. •...
Page 26 Installing the Radio Cautions z Create a loop (slack) in the co-axial cable directly underneath the antenna and fasten it so that the weight of the cable does not pull on the antenna or connector itself. z Install the antenna taking into consideration the securing supports and how the guying wires are positioned, so that the antenna does not fall over or get blown away in strong winds.
Page 27: Installing The Main Body
Installing the Radio Installing the main body Install the main body using the provided MMB-36 bracket. Select the installation location Caution Select a location where the antenna coax and power cable can be securely attached. Tip Also refer to “Installation location when used in a mobile unit” ( P.24).
Page 28: Installing The Controller
Installing the Radio Installing the controller Install the controller using the provided bracket. Caution The bracket can be bent by hand to match the location where the controller is going to be installed. Take due care not to injure yourself when bending the bracket. Select the installation location Caution Select a stable, flat location with as few dents and protrusions as possible.
Page 29: Connecting The Radio
Connecting the Radio Connecting the controller to the main body Caution Make sure the power supply is switched OFF before connecting the cable between the controller and the main body. Plug the connector of the controller cable into the 本体 Main [CONTROL] jack at the front of the main body body until a click sound is heard コントロール...
Page 30: Connecting The Power Supply
Connecting the Power Supply Connecting the car battery When using this radio as a mobile unit, connect the DC power supply cable to the negative ground 12 V car battery. Cautions z Use the radio in a car with a negative ground 12 V DC system, where the minus (-) pole of the battery is connected to the car body.
Page 31 Connecting the Power Supply (2) Connecting the power supply cable Cautions z Do not use a DC power supply cable other than the one that is provided or specified. z Do not rout the DC power supply cable where objects may be placed on top of it or persons may step on the cable.
Page 32: Connecting The External Power Supply Equipment
Cautions z Use an external power source capable of supplying DC 13.8 V, a current capacity of 20 A or more (FTM-400XDR/DE). z Make sure to switch OFF the power of the external power source before connecting. Connect the red wire (+) of the provided DC power supply cable to the positive...
Page 33: Setting Up The Micro-Sd Card
Use a new micro-SD card when data can no longer be written or erased. • Note that Yaesu shall not be liable for any damages suffered as a result of data loss or corruption in use of the micro-SD card.
Page 34: Installing The Micro-Sd Card
Setting Up the micro-SD Card Installing the micro-SD card Press for 2 seconds or longer to switch off the power to the main body Insert the micro-SD card into the micro-SD card slot, micro-SD microSD with the terminal face on top, until a click sound is カードスロット card slot heard Cautions...
Page 35: Initializing The Micro-Sd Card
Setting Up the micro-SD Card Initializing the micro-SD card When using a new micro-SD card, initialize the micro-SD card according to the following procedure. Caution Upon initialization, all the data recorded in the micro-SD card will be erased. Check the contents of the micro-SD card before initialization. Press for one second or longer The set-up menu will be displayed.
Page 36: Basic Operations
Basic Operations Receiving Turning the power on Press for 2 seconds or longer The power will be switched on, and the display will appear on the screen. Tips • When switching the power on for the first time after purchasing, or after resetting, a screen requesting the call sign of your own station be entered, will be displayed.
Page 37: Inputing The Call Sign
Receiving Inputing the call sign When switching the power on for the first time after purchasing, or after resetting the device, a screen requesting the call sign of your own station be entered will be displayed. The call sign is used to identify the transmitting station when communicating in the digital mode.
Page 38: Switching The Operating Band
Receiving Switching the operating band The two bands are displayed at the top and bottom of the dual band screen. The frequency and the modulation mode of the “operating band” can be changed. The band that is not in operation is called the “sub-band”. Touch the frequency display area of the band that you would like to set as the operating band The characters of the tag and frequency will be...
Page 39: Adjusting The Squelch Level
Receiving Adjusting the squelch level Annoying noises can be muted when a signal cannot be detected. Band A and Band B squelch levels can be individually adjusted. Noise can be canceled more easily when the squelch level is increased but it may become more difficult to pick up weak signals. Adjust the squelch level as required.
Page 40: Tuning The Radio
Receiving Tuning the radio ● Using the knobs Turn The frequency will increase when the knob is turned in a clockwise direction and decrease when turned in a counter-clockwise direction. ● Using the microphone keys Press [UP] or [DWN] The frequency increases when [UP] is pressed, and decreases when [DWN] is pressed.
Page 41: Changing The Frequency Steps
Receiving Touch a number key The touched number will be displayed at the top of the screen. Tip Refer to Page 23 for operation of the number input screen. Touch [ENT] The display will return to the function menu and the entered frequency of the operating band will be displayed at the top of the screen.
Page 42 Receiving Turn of the operating band The frequency will change in 1 MHz steps Tip When there is no operation for three seconds, the MHz field will stop blinking and the frequency step will return to the normal step. ● Changing the frequency step to 5 MHz temporarily Press for one second or longer The kHz frequency digits will not be shown on the...
Page 43 Receiving Turn The frequency will change in steps of 5 MHz. Tip When there is no operation for three seconds, the kHz digits will be displayed and the frequency step will return to the normal step. ● Changing the frequency step using the set-up menu Press for one second or longer The set-up menu will be displayed.
Page 44: Switching The Operating Mode
Receiving Touch [7 FM AM STEP] The frequency step that is currently set up will change to orange. Turn to select the frequency step The setting will change in the following sequence: AUTO → 5.00 KHz → 6.25 KHz → 8.33 KHz (air band only) →...
Page 45: Switching The Communication Mode
Receiving Touch [V/M] The mode will change to the memory mode. The channel number will be displayed above the frequency. The name (tag) assigned to the memory channel will also be displayed. Touch [V/M] again The mode will change to the VFO mode and the frequency will return to the last frequency received.
Page 46: Switching The Modulation Mode
Receiving When operating in a fixed communication mode, switch to the communication mode using The communication mode will switch in sequence as follows each time is pressed. “ ○○ (AMS)” → “DN (V/D mode)” → “VW/DW (FR mode)” → “FM (Analog)” ▀...
Page 47: Displaying The Band Scope
Receiving Touch [TX/RX] The menu list will be displayed. Touch [MODE] to select the modulation mode The modulation mode changes in the following order each time the screen is touched: “AUTO (FM)”: Automatically switches the modulation mode to match the frequency band “FM”: Switches to the FM mode.
Page 48: Muting The Audio
Receiving Touch [SCOPE] again The display will return to the dual band screen. Muting the audio The audio in the operating band and sub-band can be muted with just one touch. Touch [MUTE] [MUTE] will turn orange and the sound will become inaudible.
Page 49: Communicating
Communicating Transmitting Press and hold the microphone [PTT] A red bar will be displayed on the left of the band display. Also, the transmission output level will be displayed in the PO meter under the VOL meter. PQRS WXYZ Talk directly into the microphone [MIC] Tip Keep the microphone at a distance of about 1 inch away from the mouth when talking.
Page 50: Adjusting The Transmit Power
Touch [Tx PWR] to select the transmit power The transmission power is changed in the following sequence, each time [Tx PWR] is touched. “HI” → “LO” → “MD” Model FTM-400XDR/DE 50 W 20 W Press The transmit power is set and the display returns to the previous screen.
Page 51: Communicating In The Fm Mode
Communicating Touch [TX/RX] The menu list will be displayed. Touch [AUDIO] The menu list will be displayed. Touch [3 MIC GAIN] to select the sensitivity The sensitivity will change in the following sequence each time the screen is touched. “MIN” → ”LOW” → “NORMAL” → “HIGH” → “MAX” Tips •...
Page 52: Communicating Using The Repeater
The repeater shift width can be changed under “CONFIG” → “6 RPT SHIFT FREQ”. ● Repeater shift The FTM-400XDR/DE has been configured, at the factory, for the repeater shifts customary in the country where it is sold. For the 144 MHz band, this usually will be 600 kHz, while the 430 MHz shift will be 1.6 MHz or 7.6 MHz.
Page 53 Communicating Touch [CONFIG] The menu list will be displayed. , or touch the screen to select [4 AUTO RPT Turn SHIFT] Touch [4 AUTO RPT SHIFT] to select “ON” The setting will switch between “ON” and “OFF” each time it is touched. Press for one second or longer The automatic repeater shift will be set and the display will return to the previous screen.
Page 54: Other Settings
Other Settings Changing the beep volume The volume of the confirmation beep that goes off when a key is pressed can be adjusted. Press for one second or longer The set-up menu will be displayed. Touch [CONFIG] The menu list will be displayed. Touch [8 BEEP] to select the volume The volume changes in the following sequence each time the screen is touched.
Page 55: Locking The Knobs And Switches
Other Settings Locking the knobs and switches The knobs and switches etc. can be locked to avoid inadvertent changes and unintended operation. Press quickly “LOCK” will appear in the display and the display will return to the previous screen. Press quickly one more time to cancel the lock. “UNLOCK”...
Page 56: Adjusting The Date And Time
Other Settings Adjusting the date and time This radio has a built-in clock. Adjust the time before using. Press for one second or longer The mode will change to the set-up mode. Touch [CONFIG] The menu list will be displayed. Touch [1 DATA & TIME ADJUST] The screen for setting the date and time will be displayed.
Page 57 Other Settings Touch [+] and [-] to set the day Touch [SET] “Year” will blink. Touch [+] and [-] to set the year Touch [SET] “Hour” will blink. Touch [+] and [-] to set the hour Touch [SET] “Minute” will blink. Touch [+] and [-] to set the minute...
Page 58: Adjusting The Display Brightness
Other Settings Touch [SET] Press for one second or longer The date and time will be set and the display will return to the previous screen. Tips • The time will be displayed at the top right of the display. • You can also return to the previous screen by touching [BACK] three times.
Page 59 Other Settings Select [5 LCD BRIGHTNESS] and touch the screen The screen for selecting the level will be displayed. Touch [+] and [-] to select the brightness level The setting changes by one level each time the screen is touched. The brightness level can be selected from one of the following seven levels.
Page 60: Changing The Background Color Of The Frequency Display Area
Other Settings Changing the background color of the frequency display area The background (shade) of the frequency display can be selected from five colors. Press for one second or longer The set-up menu will be displayed. Touch [DISPLAY] The menu list will be displayed. Touch [3 BACKGROUND COLOR] to select the color The setting changes in the following sequence each time the screen is touched.
Page 61: Reconfiguring The Settings
Reconfiguring the Settings The settings and memory of this radio can be returned to be default factory settings when it was first shipped. Press for one second or longer The set-up menu will be displayed. Touch [RESET/CLONE] The menu list will be displayed. The following resets can be selected.
Page 62: Dg-Id / Dp-Id Function
DG-ID / DP-ID Function Digital Group ID (DG-ID) feature The DG-ID function can set up two-digit DG-ID numbers from “00” to “99” separately for Transmit and Receive. By setting both transmit and receive to “00” (default), you can communicate with all the other stations in the digital C4FM mode.By matching the transmit DG-ID number to the uplink DG-ID number set in club the DR-2X/XE System Fusion II digital repeater, you can access the digital repeater DR-2X/XE used in the club.
Page 63 Digital Group ID (DG-ID) feature Press and hold to save the setting and return to I D : T 5 O / R X 5 O VF O       normal operation. • The group members with same DG-ID number VF O may communi-cate with each other at the same ...
Page 64: Digital Personal Id (Dp-Id) Feature
Digital Personal ID (DP-ID) feature Every C4FM digital transmit communication contains the individual ID information (Radio ID) of each transceiver. The DP-ID function uses this individual ID information.When communicating with another transceiver, if the DP-ID of the stations are registered in each other‘s transceivers, they can communicate even if the DG-ID numbers are different. Registering the DP-ID to a DR-2X/XE digital repeater Tip To register the transceiver DP-ID in the System Fusion II, DR-2X/XE C4FM digital repeater, refer to...
Page 65: Deleting The Registered Dp-Id
Digital Personal ID (DP-ID) Feature Touch [OK?] to save the setting. • When registering in the DP-ID list is finished, then  D P - I D L I S T the display returns to the DP-ID list screen. 1 J Q 1 Y B F - 1 2 3 ZZ113 •...
Page 66: Using The Memory
Using the Memory Frequently used frequencies and settings can be saved in the memory so that you can quickly and conveniently operate on present channel. The radio is also equipped with the following memory functions: · Skips memory channels that you do not wish to receive during scanning ( P.81) ·...
Page 67: Recalling The Memory
Using the Memory Tips • When shipped from the factory, the frequency in memory channel 1 of Band A is set to 144.000 MHz while the frequency in memory channel 1 of Band B is set to 430.000 MHz. These can be changed to other frequencies but cannot be erased.
Page 68: Changing The Frequency Of The Home Channel
Using the Memory Touch [HOME] The home channel will be shown in the display. Tip Change the frequency using to return to the VFO mode. Touch [HOME] again to return to the VFO mode and display the frequency that was selected before the home channel was recalled.
Page 69: Erasing The Memory
Using the Memory Touch [OK?] to confirm and store the home channel frequency When the writing to the home channel is completed, the updated home channel frequency will be displayed. Tip Touch [Cancel] to stop writing. Erasing the memory Touch [V/M] for 2 to 3 seconds The memory list will be displayed.
Page 70: Naming The Memory
Using the Memory Naming the memory Names (memory tags) such as call signs and the names of the broadcasting stations can be assigned to the memory channels and home channel. Up to eight of the following characters can be entered as a memory tag. •...
Page 71: Changing The Method Of The Memory Tag Display
Using the Memory Touch [123] The number and symbols input screen will be displayed. Touch [0] and then [1] Touch [ENT] The name will be stored in memory and displayed on the right side of the frequency. Touch [BACK] The display will return to the previous screen. Changing the method of the memory tag display The method of displaying the frequency and name assigned to the memory can be selected for each channel.
Page 72: Split Memory
Using the Memory Touch [1 ALPHA TAG SIZE] to select the memory tag display size The setting will switch between “SMALL” and “LARGE” each time it is touched. “SMALL”: Display the memory tag in small-sized characters and the frequency in large- sized characters. “LARGE”: Display the memory tag in large-sized characters and the frequency in small- sized characters.
Page 73 Using the Memory Enter the transmit frequency The entered frequency will be displayed on the right side of [T] at the top of the screen. Touch [ENT] The display will return to the memory writing screen. Turn to select the memory channel Tip The memory channel can also be selected by touching it directly.
Page 74: Receiving Weather Broadcast Channels (Usa Version Only)
Using the Memory Touch [TX IN] The number input screen will be displayed. Enter the transmit frequency The entered frequency will be displayed on the right side of [T] at the top of the screen. Touch [ENT] The display will return to the memory list. Press to save the transmit frequency When memory writing is complete, the receive frequency will be shown in the...
Page 75: Assigning The "Wx" Function To A Programmable Key On The Microphone
Using the Memory Assigning the “WX” function to a programmable key on the microphone Press for one second or longer The set-up menu will be displayed. Select and touch [CONFIG] The menu list will be displayed. Select and touch [10 MIC PROGRAM KEY] The setting screen for programmable keys on the microphone will be displayed. Touch the key name (P1 to P4) where the WX function is going to be assigned The functions that can be assigned will be displayed.
Page 76: Scanning
Scanning Signal Search The FTM-400XDR/DE transceiver is equipped with a scanning function to search for memory channels and VFO frequencies for active signals. Scanning can be performed using the following four methods: VFO scan Scan for all memory channels Scan for specified memory channels Scanning the programmable memories The band scope function can be used to search for active channels and show a graph.
Page 77: Setting The Receive Operation When The Scanning Stops
Signal Search ● To stop the scanning To stop the scanning, either touch [SCAN] or press the microphone [PTT] button (the radio will not transmit in this case). Setting the receive operation when the scanning stops Any of the following three methods can be selected as the action to be taken after the scanning stops.
Page 78: Memory Scan
Signal Search Memory scan The FTM-400XDR/DE transceiver will scan the frequencies registered in the memories in the order of the memory channel number. Switch to the memory mode Press briefly The function menu will be displayed. Touch [SCAN] When [SCAN] is not displayed in the function menu, touch [BACK] or [FWD] to switch the menu.
Page 79: Selecting The Scanning Method
Signal Search Selecting the scanning method The scanning may be set for all memories or only specified memories. Press for one second or longer The set-up menu will be displayed. Touch [MEMORY] The menu list will be displayed. Touch [2 MEM SCAN TYPE] to select the scanning method The setting will switch between “ALL MEM”...
Page 80: Scan Only The Specified Memory Channels
Signal Search Select the memory channel to be specified by turning The memory channel may also be selected by touching it on the screen. Touch [SKIP/SEL] to display “SELECT” The setting displayed under [SKIP/SEL] will change in the following order each time it is touched. “OFF”...
Page 81: Setting The Memories To Be Skipped
Signal Search Touch [2 MEM SCAN TYPE] and select “SELECT MEM” The setting will switch between“ALL MEM” and “SELECT MEM” each time it is touched. Press for one second or longer The display will return to the previous screen. Press The function menu will be displayed. Touch [SCAN] The scan only those memory channels that have been set to “SELECT”...
Page 82 Signal Search Touch [SKIP/SEL] to display “SKIP” The setting displayed under [SKIP/SEL] will change in the following order each time it is touched. “OFF” → “SKIP” → “SELECT” Repeat Steps 2 and 3 to specify the other memories next. Touch [BACK] Return to the previous screen, and a blinking “”...
Page 83: Scanning The Programmable Memories (Pms)
Signal Search Scanning the programmable memories (PMS) Using the dedicated memory channel, only the frequencies within the specified frequency range will be scanned. The frequency range is registered beforehand in the PMS memory channel. Writing into the programmable memory Nine pairs (P1L/P1U through P9L/P9U) of frequency ranges can be set up in the PMS memory channels.
Page 84: Scanning The Programmable Memory
Signal Search Press The display will return to the previous screen, and the memorized frequency and memory channel number will be displayed. Lower frequency P1L Upper frequency P1U Scanning the programmable memory Switch to the memory mode Recall the PMS memory of the upper frequency or lower frequency Press briefly The function menu will be displayed.
Page 85: Monitoring The Home Channel
Monitoring the Home Channel This radio is equipped with a dual receive function (also known as dual watch (DW)) which checks for a signal on the home channel approximately every three seconds while monitoring or scanning. If a signal is detected, the home channel is received for five seconds, and then monitoring or scanning with dual receive is resumed.
Page 86: Setting The Restart Condition Of Dual Receive
Monitoring the Home Channel Setting the restart condition of dual receive The dual receive restart condition when the home channel signal is detected can be selected from the following two ways. (1) Restarts dual receive after five seconds have passed (AUTO). (2) Stops dual receive and continue to receive the home channel (HOLD). Press for one second or longer The set-up menu will be displayed.
Page 87: Using The Gps Function
Using the GPS Function This radio is equipped with an internal GPS reception unit to receive and display the position information at all times. The position information can be used as in the following example. Save the position information in the memory and use it for navigation purposes Refer to “Using the backtrack function”...
Page 88: Positioning Using An External Gps Device
●When not using the radio for a long period of time When using the GPS function for the first time after purchasing the FTM-400XDR/DE transceiver, and when turning it on after It has not been used for a long period time, positioning may take several minutes in order to search for the satellites.
Page 89 Positioning Using GPS Switch off the power to the radio Plug the connector of the external device into the [EXT GPS] jack on the side of the controller unit. Switch on the power to the radio Press for one second or longer The set-up menu will be displayed.
Page 90: Checking The Satellite Capture Status
Positioning Using GPS Checking the satellite capture status The satellites acquired at the current location and the strengths of the signals can be observed on the radar-like screen. Press for one second or longer The set-up menu will be displayed. Touch [DISPLAY] The menu list will be displayed. Touch [1 DISPLAY SELECT] The screen for setting the various screens on and off will be displayed.
Page 91: Displaying The Position Information
Positioning Using GPS Displaying the position information Displaying the current position information of your station Press for one second or longer The set-up menu will be displayed. Touch [DISPLAY] The menu list will be displayed. Touch [2 TARGET LOCATION] to select “NUMERIC” Each time this is touched, the setting will switch between “COMPASS” and “NUMERIC”. Press for one second or longer The display will return to the previous screen.
Page 92: Explanation Of The Position Information Screen
Manual GM Edition for the details Example: N 35°37’ 23” (latitude 35 degrees on the GM function (download the 37 minutes & 23 seconds) manual from the YAESU website). The “DD°MM’SS”” and “DD°MM.MM’” Partner station call sign and time of ➃...
Page 93: Recording The Position Information (Gps Log Function)
Positioning Using GPS Recording the position information (GPS log function) The position information of your own station can be recorded (saved) in a micro-SD card on a regular basis. Press for one second or longer The set-up menu will be displayed. Touch [CONFIG] The menu list will be displayed. Select [18 GPS LOG] and touch the screen The screen for selecting the recording interval and switching the GPS log function ON and OFF will be...
Page 94: Checking The Route Using A Personal Computer
Positioning Using GPS Checking the route using a personal computer The route can also be displayed with commercial map software using the log data of the saved position information. Switch off the power to the radio Remove the micro-SD card Insert the micro-SD card into the personal computer card reader. Open the “FTM400D”...
Page 95 Positioning Using GPS Touch [ALTITUDE] to select “ON” Each time this symbol is touched, the setting will switch between “OFF” and “ON”. Press for one second or longer The display will return to the previous screen. Press twice briefly The altitude graph will be displayed on the screen. ●...
Page 96: Other Settings
Positioning Using GPS Other settings ● Changing the geodetic reference system Select using [CONFIG] → [16 GPS DATUM] in the set-up menu. Select the geodetic reference system which is the positioning standard. “WGS-84”: Using the global geodetic reference system for positioning. This is being used as a standard all around the world. “TOKYO MEAN”: Using the Japanese geodetic reference system for positioning.
Page 97: Using The Smart Navigation Function
Using the Smart Navigation Function Two navigation methods may be used in the smart navigation function. (1) Real-time navigation function In the C4FM digital V/D mode, the position and direction of the received partner station can be displayed in real time during the communication because the position information obtained from the GPS is transmitted at the same time as the voice signal.
Page 98: Using The Real-Time Navigation Function
Using the Smart Navigation Function ● Changing the direction of the compass panel The compass panel can be selected from “Heading UP” where the direction of your travel is always displayed at the top, or “North UP” where north is always displayed at the top. Touch the compass needle The compass panel will switch between “Heading UP”...
Page 99: Using The Backtrack Function
Using the Smart Navigation Function When a partner station comes within 50 meters of your location, a beep will sound, the compass needle display will disappear, and the scope scale will appear in green Using the backtrack function Saving the destination A maximum of three locations can be saved in the memory. ●...
Page 100 Using the Smart Navigation Function Touch [★], [L1] or [L2] The position information will be saved in the memory and the touched location will turn orange in color. When position information is already registered in [★], [L1] and [L2], the text will be displayed in green color. ●...
Page 101: Displaying The Position Of The Destination In Real Time
Using the Smart Navigation Function Touch [★], [L1] or [L2] The position information will be saved in the memory and the touched location will turn orange in color. When position information is already registered in [★], [L1] and [L2], the text will be displayed in green color. Displaying the position of the destination in real time Switch to the Compass screen Touch [★], [L1] or [L2]...
Page 102: Using The Aprs Function
When using the APRS function, the call sign and symbol etc. of your own station need to be set (initial settings). Refer to the separate Operating Manual APRS Edition for details (download the manual from our YAESU website).
Page 103: Using The Gm / Wires-X Function
The GM (group monitor) function automatically checks to find if there are any stations with the GM function in operation on the same frequency within communication range. The FTM-400XDR/DE can then display the position and distance and other information on the screen.
Page 104: Basic Methods To Use The Gm/Wires-X Function
Basic Methods to use the GM/WIRES-X function Refer to the separate Operating Manual GM Edition for other details on how to use the function (download the manual from our YAESU website). ● Displaying all the stations where the GM function is in operation Tune the frequency in Band A Press Up to 24 stations operating within the sphere of communication where the GM function is in operation.
Page 105: What Is The Wires-X Function
When the transceiver is connected to WIRES-X, the call sings of other stations and rooms on the WIRES-X are displayed. To establish a WIRES-X node station, the WIRES-X connection kit “HRI-200” sold separately is required. For details, refer to the separate WIRES-X Instruction Manual (download from the Yaesu website).
Page 106: Convenient Functions
Convenient Functions Communicating with Specified Partner Stations Using the tone squelch This radio is equipped with the CTCSS (Continuous Tone-coded Squelch System) which allows audio to be heard only when receiving signals containing the same frequency tone as the tone that has been set in the tone squelch menu. By matching the tone frequency with the partner station in advance, a quiet standby is possible.
Page 107: Using The Tone Squelch
Communicating with Specified Partner Stations Press for one second or longer The tone frequency will be set and the display will return to the previous screen. The display can also be returned to the previous screen by touching [BACK] twice. Using the tone squelch Press The function menu will be displayed. Touch [SQL] to display “T-TRX”...
Page 108: Using Digital Code Squelch
Communicating with Specified Partner Stations Press the microphone [PTT] Radio waves including the tone signal will be transmitted while [PTT] is being pressed. When alternating between transmit and receive repeatedly, set [SQL] in the function menu to “T-TRX”. Using digital code squelch This radio is equipped with a DCS (Digital Coded Squelch) function that allows audio to be heard only when signals containing the same DCS code are received.
Page 109: Using Dcs
Communicating with Specified Partner Stations Turn to select the DSC code Factory default value: 023 Touch [2 DCS CODE] The characters of the set value will turn green in color. Press for one second or longer The DCS code will be set and the display will return to the previous screen. The display can also be returned to the previous screen by touching [BACK] twice.
Page 110: Using The Pager Function
Communicating with Specified Partner Stations Using the pager function Use this function to call specified stations only by using a pager code that combines two CTCSS tones. Caution The pager function does not work in the digital mode. Use the key when beginning operations to switch the communications to the auto-mode select function (AMS) or analog mode. Setting the receive station code Press for one second or longer...
Page 111 Communicating with Specified Partner Stations Touch [RX CODE 2] twice The characters of the set value will turn orange in color. Turn to select the code Select the second code from 01 to 50. Factory default value: 47 Touch [RX CODE 2] The characters of the set value will turn green in color.
Page 112: Activating The Pager Function
Communicating with Specified Partner Stations Activating the pager function Press The function menu will be displayed. Touch [SQL] to display “PAGER” Tips • When [SQL] is not displayed in the menu, use [BACK] or [FWD] to change the menu. • The squelch type changes in the following sequence each time it is touched.
Page 113 Communicating with Specified Partner Stations Touch [TX CODE 1] twice The characters of the set value will turn orange in color. Turn to select the code Select the first code from 01 to 50. Factory default value: 05 Touch [TX CODE 1] The characters of the set value will turn green in color.
Page 114: Notification Of An Incoming Call From A Partner Station Using The Bell
● User Programmed Reverse CTCSS Decoder Touch [SQL] in the function menu to display “PRGM”. The user programmable Reverse CTCSS Decoder will mute your FTM-400XDR/DE receiver when it receives a signal containing a CTCSS tone matching your programmed tone. The tone signal frequency can be set at 100 Hz intervals between 300 Hz and...
Page 115 Communicating with Specified Partner Stations ● DCS transmission Touch [SQL] in the function menu to display “D-TX”. The radio sends out the DCS code during transmit. This can be used only when [SIGNALING] → [8 SQL EXPANSION] is set to “ON” in the set-up menu. ● Tone transmission / DCS reception Touch [SQL] in the function menu to display “TT/DR”.
Page 116: Using The Dtmf Function
Using the DTMF Function The DTMF (Dual Tone Multi Frequencies) is a “peepoppa” sound heard from a telephone receiver when a call is made on a push phone line. This radio can send out the DTMF code by using the microphone keys or recalling a memory. A DTMF code with a maximum of 16 digits can be registered in up to 9 channels in the memory.
Page 117: Transmitting The Registered Dtmf Code
Using the DTMF Function Touch the character keys to input the DTMF code The DTMF code can also be input using the character keys on the microphone. Touch [ENT] The DTMF code will be set. Repeat Steps 5 to 8 when registering additional numbers in the other channels..
Page 118: Sending Out The Dtmf Code Manually
Using the DTMF Function Turn to select the DTMF code Press the microphone [PTT] The DTMF code will be sent out automatically. Release the microphone [PTT] The transmission will continue until the DTMF signal is sent out. Sending out the DTMF code manually Press and hold down the microphone [PTT] and press [0] to [9], [✽], [#], [A] to [D] Release the microphone [PTT] The transmission will continue until the DTMF signal is sent out.
Page 119: Using The Timer Function
Using the Timer Function Using the stopwatch function This radio is equipped with a lap timer and countdown timer. These can be used by switching to the timer / clock screen. Displaying the timer / clock screen Press for one second or longer The set-up menu will be displayed. Touch [DISPLAY] The menu list will be displayed.
Page 120: Using The Lap Timer
Using the Timer Function Using the lap timer Display the timer / clock screen Touch [MODE] The lap timer will be displayed. Touch [START] The timer will start. Touch [LAP] The lap time will be saved in the memory each time it is touched. Up to 99 lap times can be saved in the memory. Touch [STOP] The timer will stop.
Page 121: Using The Countdown Timer
Using the Timer Function The lap time measured in the past will be displayed when [RECALL] is touched. When there are multiple lap times, touch [] or [] to switch between the lap times. Touch briefly twice The display will return to the previous screen. •...
Page 122 Using the Timer Function Touch [SETUP] The “Minute” will be set and the set time will be displayed in the counter. Touch [START] The countdown timer will start. When the set time has passed, a beep will sound and the time will be displayed as “00:00’00” in green characters.
Page 123: Using The Apo Function
Using the Timer Function Using the APO function When the APO (Automatic Power-off) function is set to ON, the power supply to the radio will be automatically switched off when there has been no operation for a preset period of time. A notification beep will sound one minute before the power is turned off. This helps to prevent the battery from being used up when you forget to switch the radio off when connected to a car battery.
Page 124: Using The Tot Function
Using the Timer Function Using the TOT function When the TOT (Timeout Timer) function is switched on, the radio will automatically return to the reception mode after a prescribed time has passed in the transmission mode. A notification beep will sound about 10 seconds before the radio returns to the reception mode*.
Page 125: Changing The Touch Key Function
Changing the Touch Key Function Frequently used functions in the function menu can be assigned to the touch keys at the bottom of the screen. Example: Changing [MUTE] to [SCAN] Touch [MUTE] for 4 or more seconds A list of the function keys will be displayed. The list of function keys can be scrolled by turning Touch [SCAN] The touch key [MUTE] will change to [SCAN].
Page 126: Sending And Receiving Messages And Pictures
Sending and Receiving Messages and Pictures When operating in the digital mode, messages (text) and pictures can be sent and received. Messages and pictures sent or received will be saved in the common list in the memory. Cautions z When sending or receiving messages and pictures, use the key before beginning to switch the communications to the AMS (auto mode select function) or the digital mode.
Page 127: Sorting The Messages And Pictures
Sending and Receiving Messages and Pictures Touch the selected data The contents of the data will be displayed. Tips • A picture with a resolution of 320 ✽ 240 pixels will be displayed in full screen when touched. After 10 seconds or when the picture is touched again, it will return to the original display.
Page 128: Downloading Messages And Images
Sending and Receiving Messages and Pictures ● Erasing from the list Turn or touch the screen to select the data that you want to delete Touch [DEL] A screen to confirm whether or not to delete the data will be displayed. Touch [OK?] The deletion will start. When the deletion is completed, the screen will return to the list of data.
Page 129: Sending Messages And Pictures
Sending and Receiving Messages and Pictures Sending messages and pictures Messages and pictures can be sent from this radio when operating in the digital mode. Data sent will be received by all stations operating at the same frequency in the digital mode. The following are the four types of data transmission methods. (1) Create and send a new message (2) Send a saved picture (3) Replies to a downloaded message or picture...
Page 130 Sending and Receiving Messages and Pictures Touch [ENT] The entered characters will be set and the display will return to the screen for confirming the message contents. Touch [SEND] Message transmission will start and the icon on the left side of the address will blink. The sending and receiving indicator at the top left of the screen will also change to red.
Page 131 Sending and Receiving Messages and Pictures ● Using standard message The following 19 standard text messages have been entered in the radio previously, to save on time and effort for inputting the text. Good night Send messages Send pictures on my way wait for you Pick me up Good morning Thank you Good job...
Page 132 Sending and Receiving Messages and Pictures Touch [ The standard message field under the message will disappear. Follow Steps 5 to 7 in “Creating and sending a messages” ( P.129) to enter the text when adding text. ● Registering standard messages Up to 10 texts containing a maximum of 80 characters each can be registered as standard messages.
Page 133: Sending Saved Pictures
Sending and Receiving Messages and Pictures Press The text will be saved as a standard text, and the standard message field will disappear. Tips • Text can also be registered by touching the registration number displayed. • When registering a text message under a number that already contains a standard message, the previous standard message will be overwritten.
Page 134: Replying To A Message Or Picture
Sending and Receiving Messages and Pictures Touch [FORWARD] Transmission of the picture will start and the icon on the left side of the address will blink. The sending and receiving indicator at the top left of the screen will also change to red. “Completed” will be displayed when sending of the picture is completed and the display will then return to the picture list screen.
Page 135 Sending and Receiving Messages and Pictures Touch the selected message or picture The contents of the data will be displayed. Touch [REPLY] The reply message screen will be displayed. The call sign of the calling station will be displayed in the address. The first 16 characters of the message received will be automatically inserted after “Re:”.
Page 136: Forwarding Messages And Pictures
Sending and Receiving Messages and Pictures Touch [SEND] Message transmission will start and the icon on the left side of the address will blink. The sending and receiving indicator at the top left of the screen will also change to red. “Completed” will be displayed when sending of the message is completed and the display will then return to the message list screen.
Page 137 Sending and Receiving Messages and Pictures Touch [FORWARD] Transmission of the data will start and the icon on the left side of the address will blink. The sending and receiving indicator at the top left of the screen will also change to red. “Completed” will be displayed when sending of the data is completed and the display will then return to the data list screen.
Page 138: Functions To Be Used When Necessary
Functions to be Used when Necessary Using the Bluetooth Headset The optional Bluetooth unit “BU-2” and headset SSM-BT10 are available for wireless headset operation. Hands-free communication is also possible when the VOX (Voice Operated Xmit) function is used. Other Bluetooth headsets can also be used but not all the functions are guaranteed to work normally. Mounting the Bluetooth unit “BU-2”...
Page 139 Using the Bluetooth Headset Carefully lift up the front side of the main body top cover Caution Do not lift up the top cover quickly by force. This may damage the damage cables between the speaker and main board. Unplug the speaker cables extending from the top cover to the connector on the board inside the main body first before removing the cover Caution...
Page 140: Setting The Bluetooth Headset Operation
• Using the [PTT] to switch between transmitting and receiving, or switching automatically using voice • Switching transmit and receive automatically even with low level sounds Turn the FTM-400XDR/DE on Press for one second or longer The set-up menu will be displayed.
Page 141: Identifying The Bluetooth Headset
Pairing is also carried out initially when communicating wirelessly with this radio using a Bluetooth headset. The PIN code for the Yaesu Bluetooth headset “SSM-BT10” is 0000. Check the PIN code in the operating manual of the product when using Bluetooth headsets from other companies.
Page 142 Using the Bluetooth Headset Example: When pairing the optional Bluetooth headset “SSM-BT10” Refer to the operating manual of the product used for the pairing method when using a headset other than SSM-BT10. Turn the SSM-BT10 headset OFF Press for one second or longer The set-up menu will be displayed. Touch [CONFIG] The menu list screen will be displayed.
Page 143: Using The Bluetooth Headset
Using the Bluetooth Headset Press for one second or longer The display will return to the previous screen. The “ ” icon will be displayed on the top right of the band display area. Tips • Up to 8 pairing PIN codes can be saved in BU-2. When using two or more headsets such as a spare one or a personal one, set up the respective PIN codes and carry out pairing in advance.
Page 144: Taking Pictures With The Optional Camera (Snapshot Function)
Tips • Refer to our YAESU website and catalog for the transceiver models that can transmit pictures. • The picture transmit button on the microphone can only transmit picture data after the image has been taken.
Page 145: Taking Pictures
Taking Pictures with the optional Camera (Snapshot Function) Touch [1 COM PORT SETTING] The screen for the detailed settings will be displayed. Touch [OUTPUT] to select “OFF(camera)” The setting changes as follows each time it is touched. “OFF(camera)” → “GPS OUT” → “PACKET” → “WAYPOINT” Factory default value: OFF (camera) Press for one second or longer The display will return to the previous screen.
Page 146 Taking Pictures with the optional Camera (Snapshot Function) [DEL]: Delete the picture*, then return to the original screen.*:Deleted images, can be seen on the PC. [FORWARD]: Send the picture to other transceivers. Press the microphone [PTT] button to cancel the picture transmission (the picture will be stored in the microSD card).
Page 147: Viewing A Saved Picture
The pictures can be viewed on a personal computer by reading the contents of the micro-SD card into the personal computer. Caution When the filename of the picture is changed on the personal computer, the picture can not longer be shown in the display of the FTM-400XDR/DE.
Page 148: Optional Receive Audio Record And Playback
Optional receive Audio Record and Playback The receive audio received can be recorded and then played back later using the optional voice guide unit “FVS-2”. The voice announcing the frequency of the operating band can also be heard when the announce function is set to on. Mounting the voice guide unit “FVS-2”...
Page 149 Optional receive Audio Record and Playback Slowly lift up the front side of the top cover of the main body Caution Do not lift up the top cover by force. This may result in cables connected to the boards inside the main body and the speaker inside the cover to be cut. Unplug the speaker cables extending from the top cover from the socket of the board inside the main body first before removing the cover...
Page 150: Using The Voice Memory
Optional receive Audio Record and Playback Using the voice memory The voice memory is a function for recording the audio received. The audio is saved in FVS-2 that is mounted to the radio. The saved audio can be replayed on the radio and erased later. Setting the voice memory operation Switch on the power supply to the radio Press for one second or longer The set-up menu will be displayed.
Page 151: Recording The Receive Audio
Optional receive Audio Record and Playback Recording the receive audio Press The function menu will be displayed. Touch [REC] The recording will be started. Tips • When [REC] is not displayed in the menu, use [BACK] or [FWD] to switch the menu. • Set the recording time set using “OPTION” → “3 VOICE MEMORY”...
Page 152: Erasing The Recorded Audio
Optional receive Audio Record and Playback Touch [PLAY] Replay will be started. The replay will stop automatically at the end of the selected track. Touch [STOP] to stop the replay. Press The display will return to the previous screen. Erasing the recorded audio Press The function menu will be displayed. Touch [CLR] The confirmation screen will be displayed.
Page 153: Listening To The Frequency Voice Announcement
Optional receive Audio Record and Playback Listening to the frequency voice announcement Setting the announce function operation Set the following voice announcement parameters. • Automatically reading out the frequency or not • Reading out the frequency in English or Japanese • Reading out aloud • Mute the receive audio during a voice announcement or replaying recorded audio. Press for one second or longer The set-up menu will be displayed.
Page 154: Listening To The Frequency Voice Announcement
Optional receive Audio Record and Playback Touch [VOLUME] to select the announcement volume The setting will switch between “HIGH”, “MID” and “LOW” each time it is touched. Factory default value: HIGH Touch [RX MUTE] to select ON/OFF The setting will switch between “ON” and “OFF” each time the symbol is touched.
Page 155: Copying The Radio Data To Another Transceiver
400XDR/DE. This is convenient when matching the settings of fellow stations that you communicate with frequently. Using the micro-SD card The data files saved in the FTM-400XDR/DE can be selected and copied to a micro-SD card. Copying data to a micro-SD card Insert the micro-SD card into the main body card slot...
Page 156: Copying Data From The Micro-Sd Card
Copying data from the micro-SD card Insert the micro-SD card into the FTM-400XDR/DE where the data is stored and copy the data to the card Remove the micro-SD card and insert it into the FTM-400XDR/DE that the data is going to be copied to Press for one second or longer The set-up menu will be displayed.
Page 157: Using The Clone Function
The group and member information saved in the memory using the GM function can be copied using the micro-SD card. Refer to the separate Operating Manual GM Edition for details (download the manual from the YAESU website). Using the clone function Using the clone function, all the data saved in the radio can be copied directly to another FTM-400XDR/DE.
Page 158 When the operation is terminated before completion due to loss of power during the copy (clone) operation, the FTM-400XDR/DE where the data is being copied to will automatically be reset. Check if there is any abnormality in the power supply and start the cloning operation over again...
Page 159: Using The Radio With An External Device Connected
Using the Radio with an External Device Connected The provided PC connection cable “SCU-56” and other optional cables can be used to connect the radio to a personal computer as a COM port for the following operations. • Transmitting your own station position information to the personal computer for incorporation into the map software •...
Page 160: Sending Position Information To The Computer
• Make sure to switch off the power to the radio first before connecting. • When using the PC connection cable “SCU-56”, a dedicated driver needs to be installed in the personal computer. Download and use the driver and installation manual from the YAESU website. Sending position information to the computer...
Page 161: Updating The Firmware Of The Radio
An operating software using NMEA-0183 standard GGA and RMC sentence is required to use the position information. Updating the firmware of the radio The firmware of the radio can be updated by connecting to a personal computer when Updated firmware is available.. Download and use the updated version of the firmware and the update manual from the YAESU website.
Page 162: Using The Radio As A Transceiver For Packet Communication
Using the Radio with an External Device Connected Using the radio as a transceiver for packet communication Packet communication via this radio is possible by connecting this radio to the TNC (terminal node controller). ● Preparations • TNC • Personal computer • Data cable* … Prepare a data cable to match the connecting device * We supply the following optional products. •...
Page 163 Using the Radio with an External Device Connected • Data cable “CT-163” (optional) To the personal computer etc. To the transceiver To the TNC etc. ➀ PKD (packet data input) Dsub 9 pin ➁ GND ➀ - ➂ PSK (PTT) ➁ TXD (serial data output [transceiver → PC]) ➃ RX 9600 (9600 bps packet data output) ➂...
Page 164 Using the Radio with an External Device Connected ● Set the packet communication operation Turn the radio ON Press for one second or longer The set-up menu will be displayed. Touch [DATA] The menu list will be displayed. Select and touch [1 COM PORT SETTING] The screen for the detailed settings will be displayed. Touch [OUTPUT] to select “PACKET”...
Page 165 Using the Radio with an External Device Connected Touch [DATA] to select the band to be used for the packet communication The setting changes as follows each time it is touched. “A-BAND FIX” → “B-BAND FIX” → “A=TX/B=RX” → “A=RX/B=TX” → “MAIN BAND” → “SUB BAND” Tips •...
Page 166: Other Devices That Can Be Connected
Using the Radio with an External Device Connected Press for one second or longer The display will return to the previous screen. Packet communication will be enabled. Choose the band and frequency according to the settings in the set-up menu Turn of the receive band The output level to TNC from the radio will be set. Adjust the TNC output level The input level to the radio will be set.
Page 167: Customize Menu Settings And User Preferences
Customize Menu Settings and User Preferences Using the set-up menu, the various functions of the radio can be customized to match your individual preferences and type of use. The functions are divided into menus such as display, transmission and reception, memory, device configuration etc.. It is easy to select the items that you would like to adjust from the respective lists and enter or select the settings that are easy to use.
Page 168: Set-Up Menu List
Set-up Menu List Explanation of Available settings Menu / Item function (Default values shown in BOLD) DISPLAY Screen display settings 1 DISPLAY SELECT ALTITUDE: ON / OFF when is pressed TIMER/CLOCK: ON / OFF briefly GPS INFO: ON / OFF 2 TARGET LOCATION COMPASS / NUMERIC Switch between the compass screen and the latitude and longitude display screen when using the GPS and GM functions...
Page 169 Set-up Menu List Explanation of Available settings Menu / Item function (Default values shown in BOLD) SIGNALING 6 PRG REV TONE 300 Hz - 3000 Hz 1500 Hz User programmed reverse tone frequency 7 BELL RINGER Recall sound length OFF / 1 time / 3 times / 5 times / 8 times / setting CONTINUOUS 8 SQL EXPANSION OFF / ON...
Page 170 NMEA 8 / NMEA 9 WP FILTER: ALL / MOBILE / FREQUENCY / OBJECT/ITEM / DIGIPEATER / VoIP / WEATHER / YAESU / CALL RINGER / RNG RINGER 2 DATA BAND SELECT APRS/DATA band APRS: MAIN BAND / SUB BAND / selection setting...
Page 171 Set-up Menu List Explanation of Available settings Menu / Item function (Default values shown in BOLD) DATA 4 DATA SQUELCH APRS: RX BAND / TX/RX BAND Squelch detection setting DATA: RX BAND / TX/RX BAND TX: ON / OFF APRS 1 APRS COMPASS NORTH UP / HEADING UP APRS compass display orientation 2 APRS DESTINATION Model code display APY400 Non-editable 3 APRS FILTER...
Page 172 Set-up Menu List Explanation of Available settings Menu / Item function (Default values shown in BOLD) APRS 11 APRS TX DELAY 100 ms / 150 ms / 200 ms / 250 ms / Data transmit delay time setting 300 ms / 400 ms / 500 ms / 750 ms / 1000 ms 12 APRS UNITS 1 POSITION: dd°mm.mm' / dd°mm'ss'' APRS display unit...
Page 173 SORT: TIME / CALLSIGN / DISTANCE function setting FILTER : ALL / MOBILE / FREQUENCY / OBJECT/ITEM / DIGIPEATER / VoIP / WEATHER / YAESU / OTHER PACKET / CALL RINGER / RANGE RINGER / 1200 bps / 9600 bps 32 VOICE ALERT...
Page 174 Set-up Menu List Explanation of Available settings Menu / Item function (Default values shown in BOLD) OPTION 1 USB CAMERA PICTURE SIZE: 160 ✽ 120 / 320 ✽ 240 Picture size / picture quality setting for the PICTURE QUALITY: LOW / NORMAL / microphone with camera HIGH 2 Bluetooth AUDIO: AUTO / FIX Bluetooth headset setting BATTERY: NORMAL / SAVE...
Page 175: Using The Set-Up Menu
Using the Set-up Menu Screen display settings Select the screen to be displayed Set the type of screen to be displayed when pressing briefly. Press for one second or longer The set-up menu will be displayed. Touch [DISPLAY] Touch [1 DISPLAY SELECT] The display setting screen will be displayed. Touch the item to be displayed Select from “ALTITUDE”, “TIMER/CLOCK”...
Page 176: Position Information Screens
Using the Set-up Menu Switching between COMPASS and POSITION INFORMATION screens When using the GPS and GM functions, the screen will switch between the “Compass Screen” and the “Position Information (Latitude and Longitude) Display Screen”. Press for one second or longer The set-up menu will be displayed. Touch [DISPLAY] Touch [2 TARGET LOCATION] to select the display content Each time this symbol is touched, the setting will...
Page 177: Setting The Display Brightness
Using the Set-up Menu Touch [4 BAND SCOPE] to select the frequency width The frequency bandwidth will switch between “WIDE” and “NARROW” each time this symbol is touched. WIDE: The frequency bandwidth will be displayed using a wide search width. NARROW: The frequency bandwidth will be displayed using a narrow search width.
Page 178: Transmit And Receive Settings
Using the Set-up Menu Touch [7 TIME/VDD] to select the display content The display content changes between “TIME” and “VDD” each time the symbol is touched. TIME: The time will be displayed. VDD: The voltage will be displayed. Factory default value: TIME Press for one second or longer The display content will be set and the display will return to the previous screen.
Page 179 Using the Set-up Menu Touch [1 AMS TX MODE] to select the AMS transmit mode. The AMS transmit mode changes in the following order each time the symbol is touched. TX M: The operating mode is automatically selected from four communication modes to match the received signal. Pressing the Microphone [PTT] momentarily, toggles between the Digital and Analog communication modes.
Page 180: Setting The Pop-Up Time For The Partner Station Information
The pop-up time will be set and the display will return to the previous screen. Setting the display method for my position Refer to the separate Operating Manual GM Edition (download the manual from the YAESU website). Setting the Standby Beep When communicating in a digital mode, a beep is sounded after the end of the other stations transmission.
Page 181: Displaying The Version Of The Dsp Program
Using the Set-up Menu Touch [DIGITAL] Touch [4 STANDBY BEEP] to select OFF/ON The setting will switch between “ON” and “OFF” each time the symbol is touched. OFF: Disable the STANDBY BEEP feature. ON: Enable the STANDBY BEEP feature. Factory default value: ON Press for one second or longer The display will return to the previous screen.
Page 182: Setting The Sensitivity Of The Microphone
Using the Set-up Menu Touch [1 SUB BAND MUTE] to select OFF/ON The setting will switch between “ON” and “OFF” each time the symbol is touched. OFF: The sub-band audio will not be muted when a signal is received on the main band. ON: The sub-band audio will be muted when a signal is received on the main band.
Page 183: Recalling Only Specified Stations
Using the Set-up Menu Recalling only specified stations The function for calling only specified stations using the pager code can be set. Refer to “Using the pager function” ( P.110) for details. Setting the user programmed reverse CTCSS tone The frequency of the user programmed reverse CTCSS tone squelch can be set at100 Hz intervals between 300 Hz and 3000 Hz Press for one second or longer...
Page 184: Using The Bell Notification Of An Incoming Call From A Partner Station Using The Bell
Using the Set-up Menu Using the bell Notification of an incoming call from a partner station using the bell Notification of an incoming call from a partner station can be provided by a bell sound. Refer to “Notification of an incoming call from a partner station using the bell” ( P.114) for details. Setting the squelch type separately for transmit and receive Different squelch types can be used for transmit and receive. Press for one second or longer The set-up menu will be displayed.
Page 185: Scan Settings
Using the Set-up Menu Touch [9 WX ALERT] to select OFF/ON The setting will switch between “OFF” and “ON” each time it is touched. OFF: The weather alert will not be received. ON: The weather alert will be received. Factory default value: OFF Press for one second or longer The weather alert operation will be set and the display will return to the previous screen.
Page 186: Setting The Receive Operation When The Scanning Stops
The GM (group monitor) function automatically checks to find if there are any registered members within communication range. Refer to the separate Operating Manual GM Edition for further details (download the operating manual from the YAESU website). Settings on the functions and configuration Setting the date and time The date and time of the radio can be set.
Page 187: Setting The Display Format For The Date And Time
Using the Set-up Menu Setting the display format for the date and time The display format of the clock inside the radio can be changed as follows. · Date format: Month/Day/Year format, Year/Month/Day format, Day/Month/Year format, Year/Day/Month format · Time format: 24 hours format, 12 hours format Press for one second or longer The set-up menu will be displayed.
Page 188: Setting The Time Zone
Using the Set-up Menu Press for one second or longer The display format for the date and time will be set and the display will return to the previous screen. Setting the time zone The time of the clock inside the radio can be synchronized with the time in the time data (Coordinated Universal Time) from the GPS.
Page 189: Setting The Auto Repeater Shift
When communicating using the repeater, the repeater auto shift function automatically shifts the transmit frequency to match the repeater input frequency This allows the repeater to be used by simply tuning the FTM-400XDR/DE to the repeater output frequency This setting may turned ON or OFF.
Page 190: Setting The Shift Width Of The Repeater
Using the Set-up Menu Touch [5 RPT SHIFT] to select the shift direction The setting will switch between “OFF”, “-” and “+” each time it is touched. OFF: The transmit frequency will not shift. -: The transmit frequency will shift down. +: The transmit frequency will shift up. Factory default value: Differs depending on frequency Press for one second or longer...
Page 191: Setting The Frequency Step
Using the Set-up Menu Touch [6 RPT SHIFT FREQ] The characters of the set value will turn green in color. Press for one second or longer The offset of the repeater shift function will be set and the display will return to the previous screen. Setting the frequency step The change in the frequency when the tuning knob is turned, or when the key is pressed can be set.
Page 192: Setting The Program Key Of The Microphone
Using the Set-up Menu Press for one second or longer The clock shift type will be set and the display will return to the previous screen. Setting the program key of the microphone Functions can be assigned to the program keys (P1 to P4) of the provided microphone (MH-48). Press for one second or longer The set-up menu will be displayed.
Page 193: Expanding The Receive Range
Using the Set-up Menu Set other program keys Repeat Steps 4 to 6 to set the functions to be assigned to other program keys. Press for one second or longer The function will be assigned to the program key and the display will return to the previous screen.
Page 194: Setting The Unit Display
Using the Set-up Menu Setting the unit display The unit to be used when displaying the altitude, distance and speed can be set. Press for one second or longer The set-up menu will be displayed. Touch [CONFIG] Touch [12 UNIT] to set the unit The setting switches between “METRIC” and “INCH” each time it is touched.
Page 195: Setting The Geodetic Reference System Of The Gps Function
Using the Set-up Menu Setting the geodetic reference system of the GPS function The geodetic reference system which serves as the positioning standard of the GPS function can be set. Press for one second or longer The set-up menu will be displayed. Touch [CONFIG] Touch [16 GPS DATUM] to set the geodetic reference system The setting switches between “WGS-84”...
Page 196: Data Communication Settings
Using the Set-up Menu Data communication settings Setting the COM port The communication speed and function when using the [DATA] jack at the back of the main body as a COM port can be set. Press for one second or longer The set-up menu will be displayed. Touch [DATA] Touch [1 COM PORT SETTING] The screen for the detailed settings will be displayed.
Page 197 Using the Set-up Menu Touch [OUTPUT] to select the output function of the COM port The setting changes as follows each time it is touched. “OFF(camera)” → “GPS OUT” → “PACKET” → “WAYPOINT” OFF (camera): The output function of the COM port is not used (invalid operation). GPS OUT: Outputs the GPS data obtained by the radio.
Page 198 DIGIPEATER: Outputs only the digital repeater station. VoIP: Outputs only VoIP stations such as WIRES. WEATHER: Outputs only the weather station. YAESU: Outputs only stations which are using Yaesu transceivers. CALL RINGER: Outputs only the information of the call sign ringer station set using [10 APRS RINGER (CALL)] in the APRS set-up menu.
Page 199: Setting The Operating Band Of The Aprs And Data Communication
Using the Set-up Menu Setting the operating band of the APRS and data communication The operating band of the APRS (internal modem) and data communication (when using the [DATA] jack at the back of the main body) can be set. Press for one second or longer The set-up menu will be displayed. Touch [DATA] Touch [2 DATA BAND SELECT] The screen for the detailed settings will be displayed.
Page 200: Setting The Baud Rate Of The Aprs And Data Communication
Using the Set-up Menu Press for one second or longer The operating band of the APRS and data communication will be set and the display will return to the previous screen. Setting the baud rate of the APRS and data communication The baud rate of the APRS (internal modem) and data communication (when using the [DATA] jack at the back of the main body) can be set.
Page 201: Setting The Output Condition Of The Squelch Detection And Squelch Terminal
Using the Set-up Menu Setting the output condition of the squelch detection and squelch terminal The squelch detection condition during APRS (internal modem) operation and squelch terminal output condition of the data communication (when using the [DATA] jack at the back of the main body) can be set. Press for one second or longer The set-up menu will be displayed.
Page 202: Aprs Function Settings
The APRS function of the radio is a data communication system for data such as messages and station position using the APRS format. Refer to the separate Operating Manual APRS Edition for details (download the manual from the YAESU website).
Page 203: Micro-Sd Card Settings
Writing settings to the micro-SD card Using a micro-SD card, the memory channels registered in the radio and the settings in the set-up menu can be copied to another FTM-400XDR/DE. The settings saved in the micro-SD card can also be downloaded into the radio. Refer to “Copying the Radio Data to another transceiver” ( P.155) for details.
Page 204: Setting The Operation Of The Bluetooth Headset
Using the Set-up Menu Touch [PICTURE SIZE] to set the picture size The setting changes between “160✽120” and “320✽240” each time it is touched. • Factory default value: 320✽240 (unit: pixel) • It takes about 30 seconds to sending a picture in the size of 320✽240 to other transceivers. Touch [PICTURE QUALITY] to set the picture quality The setting will change in the following order each time it is touched.
Page 205: Recalling The Registered Preset
Using the Set-up Menu Touch [RESET/CLONE] Touch [2 PRESET] The screen for confirming the preset registration will be displayed. Touch [OK?] The preset will be registered. When canceling the registration, touch [Cancel]. Press for one second or longer The display will return to the previous screen. Recalling the registered preset The registered preset can be recalled from the set-up menu.
Page 206: Sorting The Registered Memory Channels
The power will be switched off once and then it will be switched on automatically. Copying saved data All the data saved in the radio can be copied directly to another FTM-400XDR/DE. Refer to “Using the clone function” ( P.157) for details.
Page 207: Call Sign Settings
Using the Set-up Menu Call sign settings Changing the call sign You can change your own call sign set in the radio. Press for one second or longer The set-up menu will be displayed. Touch [CALLSIGN] The current call sign will be displayed. Touch [CHANGE] The character input screen will be displayed. Touch a character key The touched character will be displayed at the top of the screen.
Page 208: Appendix
Appendix Options List ⑥ ① ② ③ ⑦ ⑩ ⑨ ⑧ ④ ⑪ ⑤ Cloning cable (CT-166) Speaker microphone with camera (MH-85A11U) Voice guide unit (FVS-2) Microphone extension kit (MEK-5) Bluetooth unit (BU-2) Hand Microphone (MH-42C6J) Control cable (CT-162) DTMF Microphone (MH-48A6JA) Controller bracket (MMB-98) *Same as the one provided Water proof (equivalent to IP55) high power...
Page 209: Maintenance
Maintenance Care and maintenance Turn the transceiver OFF before wiping away any dust and stains on the radio using a dry and soft cloth. For stubborn stains, slightly moisten a soft cloth and wring it hard before using it to wipe away the stains. Caution Never use washing detergents and organic solvents (thinner, benzene etc.).
Page 210: When You Have Difficulties
When you have difficulties ... Caution Check the following before requesting for repair services. There is no power z Is the external power supply connected correctly? Connect the black wire to the negative (-) terminal and the red wire to the positive (+) terminal. z Is the voltage and current capacity of the external power supply sufficient? Check the voltage (13.8 V) and current capacity (20 A or above) of the external power supply.
Page 211: About Internal Spurious Signals
 You may also check with us for any non-warranty repairs We will repair at your expense if the functions can be maintained after the repair. Please check with the retail store or Yaesu customer support for more information.  Keep the packaging box When transporting this product for inspection and repair, use the original product packaging box to...
Page 212: Specification
Specification ● General Frequency range : TX 144 - 146 MHz or 144 - 148 MHz 430 - 440 MHz or 430 - 450 MHz : RX 108 - 137 MHz (Air Band) 137 - 174 MHz (144 MHz HAM) 174 - 400 MHz (GEN1) 400 - 480 MHz (430 MHz HAM) 480 - 999.99 MHz (GEN2) Channel steps...
Page 213 Ratings ● Receiver Circuit type : Double conversion super-heterodyne Intermediate frequencies : A band: 1st : 47.25 MHz, 2nd :450 kHz B band: 1st : 44.85 MHz, 2nd : 450 kHz Receiver Sensitivity 108 - 137 MHz (AM) 0.8μV typ for 10 dB SN 137 - 140 MHz (FM) 0.2μV for 12 dB SINAD 140 - 150MHz (FM)
Page 214: Index
Index checking the route using a personal computer ..........94 About internal spurious signals ....211 clock shift of the CPU ......191 accessories ..........13 clone function ......... 157 after-market services .......211 communicating ......... 49 alphabet input screen ....... 23 communicating with specified partner altitude stations ...........
Page 215 Index display contrast ........177 display method for my position ....180 initialization and saving settings ..... 204 display mode ..........20 inputting the character ......23 DISP/SETUP key ........14 installation location when used in a mobile distance scale........... 95 unit............
Page 216 Index copying data to ........155 displaying the current ......91 initializing ..........35 displaying the partner station ....91 Initializing ........... 203 recording ..........93 installing ..........34 position information display screen ..176 removing ..........34 position information screen ...... 92 setting up ..........
Page 217 Index screen............18 transmitting the tone signal ....107 screen display settings ......175 tuning the radio......... 40 Select the screen to be displayed ..175 turning the power on......... 36 sensitivity of the microphone .... 50, 182 Setting the receive station code ....110 unit display ..........
Page 218 Note...
Page 219 SERVICE SIGNALS IS PROHIBITED UNDER FCC RULES AND FEDERAL LAW. EU Declaration of Conformity We, Yaesu Musen Co. Ltd of Tokyo, Japan, hereby declare that this radio equipment FTM-400XDE is in full compliance with EU Radio Equipment Directive 2014/53/EU. The full text of the Declaration of Conformity for this product is available to view at http://www.yaesu.com/jp/red...
Page 220 Copyright 2022 YAESU MUSEN CO., LTD. All rights reserved. No portion of this manual may be reproduced without the permission of YAESU MUSEN CO., LTD. YAESU MUSEN CO., LTD. Tennozu Parkside Building 2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan YAESU USA...
