Using WIRES-X Node Operations after the

1. Changing the WIRES-X node station setting

After this update, Change the DSQ of the node station to a DG-ID setting (00 to 99).

With this update, the conventional DSQ 001 to 126 cannot be used. After updating, set a DG-ID of 00 to

99 to the node station.

1. Start the WIRES-X PC software on the PC.

2. From the "File" menu, click "Transceiver".

The "Transceiver" window will appear.

3. Set the desired DG-ID.

DG-ID numbers that can be set (00 to 99)

Example

DG-ID

Setting value

01 - 99

Be sure to select a DG-ID setting from 00 to 99.

4. Click "OK" to complete the setting.

DG-ID function update

FTM-400XDR/XDE/DR/DE

OFF

001 - 099

Table of Contents

Do you have a question about the FTM-400XDR and is the answer not in the manual?

Page 1 Using WIRES-X Node Operations after the DG-ID function update FTM-400XDR/XDE/DR/DE 1. Changing the WIRES-X node station setting After this update, Change the DSQ of the node station to a DG-ID setting (00 to 99). With this update, the conventional DSQ 001 to 126 cannot be used. After updating, set a DG-ID of 00 to 99 to the node station.
Page 2 With this update, the conventional DSQ (digital squelch) function cannot be used. After updating, use the DG-ID function to access the node station. How to access the WIRES-X node station from the FTM-400XDR/XDE/DR/DE 1. Press and hold the [DISP] (SETUP) key to enter the Set-up Menu.
