Information for Customers Operating VHF/UHF Transceivers in the UK

Thank you very much for purchasing the YAESU transceiver.
The transceivers listed in this notice are configured at the factory with the ARS (Automatic Repeater Shift) Frequency
Range, and the Repeater shifts, as shown in the below chart "ARS Configuration B2".
When any of the listed transceivers is operated in a location where the frequency range and repeater shifts in use are
as shown in the chart "ARS Configuration C2"; follow the respective procedure to change the Automatic Repeater
Shift configuration, before using the transceiver for the first time.
ARS Configuration "B2"
Factory Default Setting
ARS Frequency Range: 438.20 MHz - less than 439.45 MHz ( - shift )
Repeater Shifts: 7.6 MHz

FTM-400XDE

1. Turn the transceiver OFF.
2. Connect the supplied microphone MH-48A6JA to the
transceiver.
3. Press and hold the [ F ( MW )] and [ GM ] keys while turn-
ing the transceiver ON.
4. Press the [ Power ] key briefly, then "LOCK" will appear
on the display for one sec.
5. Press [ 8 ] à [ 3 ] à [ 7 ] à [ 8 ] à [ 3 ] à [ 7 ] keys on the
MH-48A6JA microphone.
6. Press the [ Power ] key briefly, then "UNLOCK" will ap-
pear on the display for one sec.
7. Press and hold the [ DISP ( SETUP )] key.
8. Touch the [ RESET/CLONE ] on the display.
SETUP MENU
DISPLAY
TX/RX
SIGNALING
SCAN
W  RES
CONFIG
APRS
SD CARD
RESET/
BACK
BACK
CLONE
9. The ARS Configuration name "B2" will appear in the
top right of the display.
RESET/CLONE
FACTORY RESET
PRESET
RECALL PRESET
MEM CH RESET
BACK
BACK
10. Press [ F ( MW )] key, then the message <Confirming
FROM "B2" TO "C2"> will appear on the display.
11. Touch [ OK? ] . The radio will re-start automatically.
Setting of the ARS feature to "Configuration C2" is
successfully completed.
RESET/CLONE
FACTORY RESET
PRESET
Confirming
FROM "B2" TO "C2"
RECALL PRESET
O K ?
MEM CH RESET
BACK
BACK
To restore the ARS feature setting to the factory default
( B2 ) , perform the same procedures above.
ARS Frequency Range: 433.00 MHz - less than 433.40 MHz ( + shift )
Repeater Shifts: 1.6 MHz
MEMORY
DATA
OPTION
CALLSIGN
VERSION
MAIN : x . x x x 0EXP B2
PANEL: x . x x
VERSION
MAIN : x . x x x 0EXP B2
PANEL: x . x x
Cance
ARS Configuration "C2"
Selectable Setting
434.60 MHz - less than 435.00 MHz ( - shift )

FTM-100DE

1. Turn the transceiver OFF.
2. Connect the supplied microphone MH-48A6JA to the
transceiver.
3. Press and hold the [ A/B ( DW )] and [ GM ] keys while
turning the transceiver ON.
4. Press the [ Power ] key briefly, then "LOCK" will appear
on the display for one sec.
5. Press [ 8 ] à [ 3 ] à [ 7 ] à [ 8 ] à [ 3 ] à [ 7 ] keys on the
MH-48A6JA microphone.
6. Press the [ Power ] key briefly, then "UNLOCK" will ap-
pear on the display for one sec.
7. Press and hold the [ DISP ( SETUP )] key.
8. Rotate the DIAL to select [ 13 RST/CLONE ] , then
press the [ DISP ( SETUP )] key.
9. Rotate the DIAL to select [ 8 SOFTWARE VERSION ] ,
then press the [ DISP ( SETUP )] key.
10. The ARS Configuration name "Region "EXP" Type "B2"
will appear in the bottom on the display.
11. Press [ BAND ( MHz )] key, then the message <FROM
"B2" TO "C2"> appears on the display.
12. Rotate the DIAL to select [ OK? ] , and then press the
[ DISP ( SETUP )] key . The radio will re-start automati-
cally. Setting of the ARS feature to "Configuration C2"
is successfully completed.
To restore the ARS feature setting to the factory default
( B2 ) , perform the same procedures above.
