Hardware Installation and Reference Guide
Figure 1-2 Front Panel of RG-EG105G-V3
Mark
1
2
3
Caution
Reset button: Press the button for less than 2 seconds, the system will restart; press for more than 5 seconds
until the system status LED blinks, the system will restore the factory settings and restart. After the device
restores the factory settings, the default management address is
Figure 1-3 Back Panel of RG-EG105G-V3
1.3

Power Supply

The RG-EG105G-V3 router adopts AC power input.
AC input:

Rated voltage range: 100V to 240V, 50Hz/60Hz

Maximum voltage range: 90V to 264V, 47Hz to 63Hz

Frequency: 50Hz/60Hz

Rated current: 0.3A
Item
System status LED
Reset button
Power supply
Mark
4
5
6
http://192.168.110.1
3
Product Overview
Item
LAN ports
LAN/WAN port
WAN port
(default password: admin).
