Hardware Installation and Reference Guide
Operating Bands
Antenna Type
Spatial Streams
Transmission Rate
Modulation
Receive Sensitivity
Maximum Transmit
Power
Adjustable Power
Dimensions (W × D
× H)
Weight
Service Ports
LEDs
Power Supply
802.11b/g/n: 2.4 GHz to 2.4835 GHz
802.11a/n/ac: 5 GHz: 5.150 GHz to 5.350 GHz, 5.47 GHz to 5.725 GHz, 5.725
GHz to 5.850 GHz
Note: The operating band varies in different countries.
Built-in omnidirectional antenna
2.4 GHz: 2 x 2 MIMO
5 GHz: 2 x 2 MIMO
Radio 1: 2.4 GHz, 400 Mbps
Radio 2: 5 GHz, 867 Mbps
Maximum access rate per device:
OFDM: BPSK@6/9 Mbps, QPSK@12/18 Mbps, 16QAM@24/36 Mbps,
64QAM@48/54 Mbps
DSSS: DBPSK@1 Mbps, DQPSK@2 Mbps, and CCK@5.5/11 Mbps
MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM
11b: –91 dBm (1 Mbps), –88 dBm (5.5 Mbps), –85 dBm (11 Mbps)
11a/g: –89 dBm (6 Mbps), –80 dBm (24 Mbps), –76 dBm (36 Mbps), –71 dBm
(54 Mbps)
11n: –83 dBm@MCS0, –65 dBm@MCS7, –83 dBm@MCS8, –65 dBm@MCS15
11ac: VHT20: –83 dBm (MCS0), –57 dBm (MCS9)
11ac: VHT40: –79 dBm (MCS0), –57 dBm (MCS9)
11ac: VHT80: –76 dBm (MCS0), –51 dBm (MCS9)
2.4 GHz: ≤ 26 dBm (Adjustable)
5 GHz: ≤ 25 dBm (Adjustable)
Note: The actual transmit power may vary in different countries and regions
according to the rules and regulations.
1 dBm
120 mm × 120 mm × 28 mm (4.72 in. × 4.72 in. × 1.10 in., without the brackets)
0.25 kg (0.55 lbs, without the brackets)
Note: The value indicates the weight of the router only.
One 10/100/1000Base-T WAN port, one 10/100/1000Base-T LAN port and three
10/100/1000Base-T WAN/LAN switchable ports
One blue system status LED and one white MESH LED (with three bars,
indicating the MESH signal strength.)
Adopt local power supply, DC adapter (12 V/1.5 A)
5
1267 Mbps
Product Overview
