Operation Mode / Standby Mode setting
Operation mode set pressure, standby mode set pressure setting method
Key operation
No
(1) Deactivate the key lock if necessary (see page 22).
(2) Press S-key
Set Operation Mode (PS1) set pressure
(3)
by using the △ and ▽ keys.
(4) Press S-key
Set Standby Mode (PS2) set pressure by
(5)
using the △ and ▽ keys.
(6) Press S-key
(7) Activate the key lock if necessary (see page 22).
(Note1)：Pressure can be adjusted from 0 to 700[kPa].
(Note2)：The adjustable range is 0 to 700[kPa], but the setting range is 0 to 1050[kPa].
(Note3)：The setting range of the LED display changes depending on the pressure display unit.
⇔
(displayed alternately)
*Adjusting range: Refer to note 1 to 3
⇔
(displayed alternately)
*Adjusting range: Refer to note 1 to 3
Display current pressure
- 23 -
LED Display
