SMC Networks ITV2050-IL20-X399 Series Operation Manual page 14

Product individual parameters
Index
Access
(decimal
Subindex
number)
0x40
0 R/W
(64)
0x41
0 R/W
(65)
0x42
0 R/W
(66)
0x43
0 R/W
(67)
0x48
0
(72)
0x49
0 R/W
(73)
0xA0
0
(160)
0x4A
0 R/W
(74)
0x4B
0 R/W
(75)
0x4D
0 R/W
(77)
0x52
0 R/W
(82)
*1: R means Read and W means Write.
*2: Refer to the table below for the symbol.
Parameter
*1 name
Pressure
display unit
Hold/clear
Gain
Sensitivity
Accumulated
R
energizing time
Notification
setting of the
accumulated
energizing time
R Product number STR64
Operation
Mode (PS1)
Standby
mode (PS2)
Solenoid Valve
Stop Time
Pressure Ramp
Up Duration
Data Data
Initial
type storage
value
*2 *3
U8 {0} Y
U8 {1} Y
U8 {9} Y
U8 {2} Y
U32 {0} Y
U32 {0} Y
{Product
N
number}
U16 {0} Y
U16 {0} Y
U8 {0} Y
U16 {0} Y
- 13 -
Details
Setting value of pressure
display unit
Pressure control setting when an
IO-Link communication error
occurs.
When {0} is set, output pressure
is cleared. When {1} is set,
output pressure is held.
The gain for the
electro-pneumatic regulator can
be adjusted in the range from 0
to 15.
The sensitivity of the
electro-pneumatic regulator can
be adjusted in the range from 0
to 7.
Displays accumulated
energizing time.
Set notification of the
accumulated energizing time.
Displays the product number.
Operation mode command
pressure PS1
Set pressure 0 to 1050 (fixed
kPa)
Standby mode command
pressure PS2
Set pressure 0 to 1050 (fixed
kPa)
Setting Solenoid Valve Stop
Time
Setting range0～99（％）
Setting the Pressure Ramp Up
Duration
Setting range 0～1500（0.1
second unit)
