- Page 1 Sideboard Version:06/08/2022 1/18...
- Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
-
Page 3: Table Of Contents
Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size A x 48 B x 48 C x 20 D x 10 E x 60 6 x 35 mm 15 x 9 mm 8 x 30 mm... - Page 4 4/18...
-
Page 5: A X 4
E x 18 A x 4 CR x 3 CL x 3 6 x 35 mm 3 x 12 mm Fix slide rail(CL) and (CR)to both side of No.3 plate with screw(E) as shown. Insert quickfit screw(A) into both side of No.3 plate as shown. - Page 6 E x 18 A x 8 CR x 3 CL x 3 6 x 35 mm 3 x 12 mm Fix slide rail(CL) and (CR)to No.2, No.4 plates with screw(E) as shown. Insert quickfit screw(A) into No.2, No.4 plates as shown. Please pay attention to the holes where the accessories are inserted and don't use an electric screwdriver...
-
Page 7: X 35 Mm
D x 2 4 x 35 mm Attach No.8 to No.3 plate with screw(D) as shown. 7/18... - Page 8 C x 4 B x 4 15 x 9 mm 8 x 30 mm Attach No.6 to No.3 plate with wooden dowel(C)and turn cam locks(B)clockwise to tighten as shown. 8/18...
- Page 9 B x 8 C x 4 15 x 9 mm 8 x 30 mm Connect No.2 and No.4 plates to the component with wooden dowel(C)and turn cam locks(B)clockwise to tighten as shown. 9/18...
-
Page 10: F X 6
Insert No.7 plate into available slots as shown. F x 6 A x 6 6 x 35 mm 4 x 50 mm Attach No.5 to No.1 plate with screw(F) as shown. Insert quickfit screw(A) into No.1 plate as shown. Please pay attention to the holes where the accessories are inserted. -
Page 11: B X 6
B x 6 C x 6 15 x 9 mm 8 x 30 mm Cover No.1 plate to the component with wooden dowel(C) and turn cam locks(B) clockwise to tighten as shown. 11/18... -
Page 12: G X 5
J x 5 G x 5 4 x 30 mm Fix part(J) into No.11 plate with screw(G) as shown. D x 6 C x 6 4 x 35 mm 8 x 30 mm Cover No.11 plate to the component with wooden dowel(C) at first, then use screw(D) to fix as shown. -
Page 13: Dl X 6
E x 24 DR x 6 DL x 6 3 x 12 mm Fix slide rail(DL) and (DR)to No.9, No.10 plates with screw(E) as shown. G x 30 4 x 30 mm Attach No.9, No.10 and No.14 to No.12 plate with screw(G)as shown. 13/18... - Page 14 A x 15 B x 15 6 x 35 mm 15 x 9 mm Insert No.13 plate into available slots as shown. Insert quickfit screw(A) into No.16 plate as shown. Attach No.16 plate to the component and turn cam locks(B)clockwise to tighten as shown.
- Page 15 A x 15 B x 15 6 x 35 mm 15 x 9 mm Insert quickfit screw(A) into No.15 plate as shown. Attach No.15 plate to the component and turn cam locks(B)clockwise to tighten as shown. 15/18...
- Page 16 Align rails, put all drawers. 16/18...
-
Page 17: M X 8
H x 8 M x 8 P x 2 Q x 2 S x 2 3 x 14 mm 4 x 14 mm 17/18... - Page 18 D x 2 Q x 2 R x 2 4 x 35 mm 6 x 30 mm 18/18...
- Page 19 WARRANTY WARRANTY CLAIMS •There is a 30-day warranty for broken furniture or any other problems that do not work properly. The warranty will start from the date of purchase which must be verified by proof of purchase. •Before making a claim, we may be able to answer your query, simply call us. Please leave your purchase order number, along with some details of the problem, if you want a replacement part.
- Page 20 RETURNS CHANGED YOUR MIND AND NEED TO RETURN YOU ITEM? PLEASE FOLLOW THE BELOW INSTRUCTIONS: •If you have purchased and have simply changed your mind, follow the retailer’s instructions for returns. DEFECTIVE ITEMS •If your item is defective in any way, i.e. it doesn’t work but you can’t identify why, in the first instance, please call us.
