Maintenance; Cleaning The Lamp; Replacing The Lamp; Troubleshooting - Field Controls Healthy Home System Duo-2000, Installation & Maintenance Instructions

This maintenance schedule is only a guideline based on average indoor air quality conditions. Actual conditions will dictate the frequency
of cleaning the UVC germicidal lamp and replacing filters. It is recommended on average that Standard Throw-Away 1" and 2" filter be
replaced every 3 months, High Efficiency 5" pleated every 6 months.

CLEANING THE LAMP

1. Unplug the quick disconnect power cord from the Duo-2000.
2. Remove the (2) Phillips head screws on the left and right
hand side of the front electrical cover and remove the cover.
(photo - D)
3. Remove the (4) wing nuts inside on the duct mounting plate
shown in (photo - B).
4. Remove the Duo-2000 body by sliding out of the duct
mounting plate.
5. Use a cotton cloth with isopropyl alcohol and gently clean
the surface of the lamp.
Note: If the honeycomb photo-catalyst on the left and right side
of the UVC germicidal lamp appears to be a light gray color and
the individual cells are open and clear, there is no need to clean
the catalyst as it is self cleaning. If for any reason the catalytic
cells require cleaning, sit the unit on end, on a flat surface, with
the electrical enclosure facing up. Spray the catalytic cells with
Windex and flush the catalyst with warm water until clean.
CAUTION: Allow the unit to thoroughly dry before
replacing into service.
6. Replace the Duo-2000 back into the duct mounting plate
and tighten the (4) wing nuts hand tight. Replace the front
electrical cover and plug the quick connect power cord back
into the unit.
Product is warranted 18 months from date of installation. This warranty does not cover broken lamps due to mishandling in shipping, installation or misuse. Shipping cost for
warranty return parts is the sole responsibility of the owner of the air purifier. This warranty is provided to the original purchaser of the air purifier and may not be transferred, sold or
bartered. This warranty gives you specific legal rights which vary from state to state.
SPECIFICATIONS D
Part# 17.5LAMP UVC Germicidal Lamp .................. 50 watts UVC
Length in Duct ....................................................... 17-3/4 inches
Duo-2000 PCO TiO Semiconductor ...................... 3500 sq. inches
2
Weight .................................................................. 3.6 lbs
Adjustable Voltage ................................................. 120 or 230 volts
Lamp Life Efficiency Output .................................... 2 years
Average static pressure drop ................................... .02 in wg (4.9817 pascals)
Application range for DUO-2000 ........................... up to 2000 cfm (5.0 tons)
Field Controls, 2630 Airport Road, Kinston, NC 28504 *(252) 522-3031* www.fieldcontrols.com
Duo-2000 UVC Photo-Catalytic Air Purifier
Installation & Maintenance Instructions

MAINTENANCE

Recommended every (24) months of continuous service.
Replace only with a Part# 46636300 17.5LAMP UVC germicidal
replacement lamp. This is a custom manufacture lamp designed
only for high output thermal compensating electronic ballast.
Follow the above steps and after (step - 4) loosen the brass knurl
nut on the clamp at the rear of the lamp. Unplug the lamp electrical
connector from the end of the lamp shown in (photo - A) and gently
slide the lamp out the front of the Duo-2000 housing. Reinstall by
reversing the above steps.
1. Check to be sure there is correct voltage to the unit and the
ballast is set for the correct voltage. (photo - A)
2. Be sure the lamp connector is fastened securely. (photo - A)
3. Check for loose electrical connections. (photo - B)
4. Test with new lamp and if lamp still does not light, replace
ballast.

WARRANTY

-2000 UVC Photo-Catalytic Air Purifier
UO

REPLACING THE LAMP

TROUBLESHOOTING

AIR FLOW
