TERMINAL CONNECTIONS

Connect the unit as in the diagram below or refer to the connection diagram on the side of the unit.
■ EXTERNAL DIMENSIONS unit: mm (inch)
36 (1.42)
STANDARD BEZEL *
2
4.9
(.19)
11.4 7.5
(.45) (.30)
*1. Space required when replacing the scale plate.
*2. Used for the existing panel cutout of M-System 48 Series (38 × 139.5 mm).
*3. Used for the existing DIN panel cutout (33 × 138 mm)
*4. Used for the existing panel cutout of Fuji Electric PAJ, PAK, PBA (44 × 138 mm), etc.
10 (.39) 75 (2.95)
103 (4.06)
OPTION /D BEZEL *
Rounded corners for the option /D
3.9
(.15)
10.4
(.41)
