FRONT PANEL CONFIGURATION

■ ALARM OUTPUT CODE 2: 2 points
• Vertical Mounting
50 100 SET
40 90
H Setpoint
30 80
20 70
10 60
0 50
L Setpoint
-10 40
-20 30
-30 20
PV Indicator
-40 10
-50 0
°C %
■ ALARM OUTPUT CODE 4: 4 points
• Vertical Mounting
50 100 SET
40 90
HH Setpoint
30 80
20 70
H Setpoint
10 60
L Setpoint
0 50
LL Setpoint
-10 40
-20 30
-30 20
PV Indicator
-40 10
-50 0
°C %
• Bar Color Patterns
Pattern 1 (Bar LED color code 1)
Input < L L < Input < H
H
green
L
orange orange
Pattern 2 (Bar LED color code 2)
H
green
L
orange green
SET (ENTER) Button
H Setpoint Adj. & Trip Indicator (red)
H
Span Adj. (amber)
S
Power Saving Mode Indicator (amber)
•
Zero Adj. (amber)
Z
L Setpoint Adj. & Trip Indicator (green)
L
UP Button
Mode Selector
M
DOWN Button
SET (ENTER) Button
HH Setpoint Adj. & Trip Indicator (red)
HH
H Setpoint Adj. & Trip Indicator (red)
H
Span Adj. (amber)
S
Power Saving Mode Indicator (amber)
•
Zero Adj. (amber)
Z
L Setpoint Adj. & Trip Indicator (green)
L
LL Setpoint Adj. & Trip Indicator (green)
LL
UP Button
Mode Selector
M
DOWN Button
H < Input
red
green
orange
red
red
red
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
• Horizontal Mounting
°C
-50 -40 -30 -20
0 10 20 30
%
M
• Horizontal Mounting
°C
-50 -40 -30 -20
0 10 20 30
%
M
48NAR
-10 0 10 20 30 40 50
40 50 60 70 80 90 100
L Z • S H
SET
-10 0 10 20 30 40 50
40 50 60 70 80 90 100
LL L Z • S H HH
SET
