Bedford
Kitchen Cart
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
PART LIST
A.
Top
1 pc.
F.
Back Stretcher
2 pcs.
H.
G.
Back Panel
Back Piece
2 pcs.
1 pc.
HARDWARE LIST
Wood Screw
Small
for Caster
Hex Wrench
16 pcs. (+1 extra)
1 pc.
Caster
two lock
two non-lock
Hex Wrench
1 pc.
4 pcs.
Tools Required For Assembly : Phillips screwdriver
Casual Attire For Today's Home
B.
Side Panel
1 pc.
I.
Shelf
1 pc.
J.
Side Bar
2 pcs.
K.
Base
1 pc.
Wood Screw (Long)
Head Cap Bolt (long)
2 pcs. (+1 extra)
8 pcs. (+1 extra)
Head Cap Bolt
Wood Screw
4 pcs. (+1 extra)
6 pcs. (+1 extra)
C.
D.
Side Panel
Front Stretcher
1 pc.
1 pc.
E.
Front Stretcher
1 pc.
N.
Drawer
1 pc.
Drawers require assembly.
L.
M.
(
Please refer to the last page
Door
Door
of these assembly instructions.
1 pc.
1 pc.
Cam Lock
Adjustable Pin
8 pcs.(+1 extra)
4 pcs. (+2 extra)
Machine Screw
Cam Lock Screw
for Side Bar
8 pcs.(+1 extra)
4 pcs.
)
Pull Handle
4 pcs.
Machine Screw
for Pull Handle
4 pcs.
