- Page 1 DVI KVM Switch （8 Port / 16 Port） User Manual www.kinankvm.com @all right reserved Shenzhen Kinan Technology Co., Ltd. Printing date：2022/04 Version：V1.2...
- Page 2 8 Port /16 Port User Manual Overview Descriptions DVI KVM switch is a control device which controls multiple computers from a single console (keyboard, video and mouse). It is easy and fast to install the KVM switch, you just need to connect corresponding cables to the right ports of the KVM.
- Page 3 8 Port /16 Port User Manual Hardware Installation Rack Mounting Make sure all the computers and external device are shut down before installation. Put the KVM switch in place, screw the brackets to the two sides of the KVM to install the KVM in the standard 19”...
- Page 4 8 Port /16 Port User Manual Rear View Instruction Grounded Screw Console DVI port Console USB port (keyboard, Mouse) KVM Port Power adapter socket Installation Diagram Make sure the KVM has been connected to the ground(①) Connect the power adapter to KVM(②) ...
- Page 5 8 Port /16 Port User Manual LED Instructions Components Function 1-8 or 1)Switching freely from port 1 to port 8/16 1-16 1）An online LED light(orange) indicates that the KVM has connected to its corresponding Port Selection computer and power on. Buttons&...
- Page 6 8 Port /16 Port User Manual Hotkey Operation Double click 【Scroll Lock】 (in 2 seconds) , when you heard the beep sound, you are in hotkey mode. If there are no any operations in Hotkey Mode in 2 second, keyboard out hotkey mouse. Hotkey commands are as follows：...
- Page 7 8 Port /16 Port User Manual Specification Model No. RDV108 RDV116 Computer Connection Port Selection Pushbutton, Hot key Monitor 1x DVI-D Console Connector Keyboard/Mouse 2x USB type A 8x DVI-D 16x DVI-D Switch Port Selection 8x buttons 16x buttons Online...
