  • Page 1 VVRDE 700 Manual Set up and user manual for the VVRDE4V9CM-700 VVRDE4V9DN-700 VVRDE4V9DNLED-700 cameras...
  • Page 3 Before You Begin Read these instructions before installing or operating this product. Note: This installation should be made by a qualified service person and should conform to local codes. This manual provides installation and operation information. To use this document, you must have the following minimum qualifications: ...
  • Page 4 RoHS Announcement All lead-free products offered by the company comply with the requirements of the European law on the Restriction of Hazardous Substances (RoHS) directive, which means our manufacture processes and products are strictly “lead-free” and without the hazardous substances cited in the directive. The crossed-out wheeled bin mark symbolizes that within the European Union the product must be collected separately at the product end-of-life.
  • Page 5 IMPORTANT SAFEGUARDS 1. READ AND RETAIN INSTRUCTIONS Read the instruction manual before operating the equipment. Retain the manual for future reference. 2. CLEANING Turn the unit off and unplug from the power outlet before cleaning. Use a damp cloth for cleaning. Do not use harsh cleansers or aerosol cleaners. 3.
  • Page 6 11. OVERLOADING Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock. 12. SERVICING Do not attempt to service the video monitor or equipment yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
  • Page 7: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ------------------------------------------------------------------------------------- ----1 CAMERA CONNECTIONS ----------------------------------------------------------------------- -----2 ADJUSTING CAMERA MODULE ---------------------------------------------------------------- ---3 INSTALLATION--------------------------------------------------------------------------------------------4 OSD ADJUSTMENT ----------------------------------------------------------------------------------- -5 OSD MAIN MENU TREE ----------------------------------------------------------------------------- -6 OSD MENU SETTINGS ------------------------------------------------------------------------------ -8 LENS ADJUSTMENT-----------------------------------------------------------------------------------13 HEATER INSTALLATION (optional part) -------------------------------------------------------- 14 SPECIFICATIONS ------------------------------------------------------------------------------------- 15 DIMENSIONS---------------------------------------------------------------------------------------------16...
  • Page 8: Introduction

    INTRODUCTION Features: ● 1/3" Sony EXview HAD CCD with Effio „e‟ DSP ● 700TVL Colour & Monochrome resolutions ● f4~9mm varifocal lens (F1.6~2.4) ● 0.32Lux (Colour) @ F1.6 sensitivity (CM version) 0.32Lux (Colour) 0.02Lux (B/W) @ F1.6 sensitivity (DN version) 0.32Lux (Colour) 0Lux (B/W) @ F1.6 sensitivity with LEDS on (DNLED version) ●...
  • Page 9: Camera Connections

    CAMERA CONNECTIONS 1. Lens: 4-9mm DC Vari-focal lens for wide area monitoring 2. Power: 12vDC / 24vAC Input (please note that with 12vDC operation power terminals are polarity dependant) If using 12vDC power input, Please use a power supply capable of supplying over 6.0 Watts (550mA).
  • Page 10: Adjusting Camera Module

    ADJUSTING CAMERA MODULE Unpack and identify the following parts from the product carton: D. „L‟ shaped Torx drive Camera B. Fixing kit C. Instruction manual Note : Make sure the camera PSU is turned off when connecting the power adaptor cable. To adjust the camera module within the 3 axis gimble, follow the directions below.
  • Page 11: Installation

    INSTALLATION CAUTION: When installing the camera outdoors, the following instructions must be followed closely. 1. Loosen the four Torx screws on the housing cover. Do NOT remove the screws from the cover. 2. Use the mounting template as a drilling guide to ensure correct positioning of the screws.
  • Page 12: Osd Adjustment

    OSD ADJUSTMENT (CM & DN) The tactile switch (under the plastic lens cover) allows both navigation and changes to the OSD Menu. To „enter‟ into the OSD menu push centrally on the tactile switch and navigate using the up, down, left and right actions. If there is an arrow to the right of the menu function, this denotes that there is an accessible sub menu function and this is accessed via the „enter‟...
  • Page 13: Osd Main Menu Tree

    OSD MAIN MENU TREE SETUP MENU (page 1) LENS SHUTTER/AGC LENS SHUTTER/AGC WHITE BAL BACKLIGHT AUTO IRIS AUTO PICT ADJUST MANUAL MANUAL MOTION DET RETURN NEXT (page2) RETURN EXIT SAVE WHITE BALANCE BACKLIGHT PUSH USER 1 USER 2 ANTI CR MANUAL PUSH LOCK RETURN...
  • Page 14 SETUP MENU (page 2) PRIVACY PRIVACY DAY/NIGHT DAY/NIGHT AREA SEL AUTO CAMERA ID COLOUR COLOUR SYNC TRANSP LANGUAGE MOSAIC CAMERA RESET BACK (page 1) EXIT SAVE RETURN RETURN CAMERA ID SYNC NR MODE (titling) Y LEVEL C LEVEL PHASE RETURN RETURN RETURN RETURN...
  • Page 15: Osd Menu Settings

    OSD MENU SETTINGS LENS MANUAL Manual lens only AUTO TYPE (DC / VIDEO) Sets the type of mechanical iris (Video lens is not supported) MODE (OPEN / CLOSE / AUTO) Sets the type of control to be applied over the mechanical iris. SPEED (0 –...
  • Page 16 WHITE BAL ATW (Auto Trace White balance) SPEED (0~255) Adjusts the pull-in speed of ATW. DELAY CNT (0~255) Sets the time-based hysteresis of ATW. ATW FRAME (X0.5/X1/X1.5/X2) Sets the pull-in frame magnification. ENVIROMENT (indoor/outdoor) Preset for either indoor or outdoor applications of the ATW PUSH Wide range Auto White Balance mode (AWB) USER1 &...
  • Page 17 PICT ADJUST MIRROR (ON/OFF) Inverts image horizontally. BRIGHTNESS (0~255) Sets the screen brightness. CONTRAST (0~255) Sets the screen contrast. SHARPNESS (0~255) Sets the screen sharpness. (0~255) Adjusts the hue. GAIN (0~255) Adjusts the gain. ATR (Adaptive Tone Reproduction) allows adjustment of the image to assist with widely contrasting scenes of view.
  • Page 18 PRIVACY AREA SEL (1~4) Selects the motion detection area TOP (0~244) 0=top BOTTOM (0~244) 244=bottom LEFT (0~474) 0=left RIGHT (0~474) 474=right COLOUR (1~8) Sets the colours of the privacy zones. TRANSP (0.00/0.50/0.75/1.00) Sets the transparency of the privacy zone area if colour is selected. MOSAIC (ON/OFF) Sets the mosaic function as the privacy to ON or OFF.
  • Page 19 NR (2D-DNR) This is used to remove noise from the image in low light conditions when AGC is applied. NR MODE (OFF, Y, C, Y/C) Sets the 2D NR filter mode. Y LEVEL (0-15) Sets the Y filter (Luminance) strength. C LEVEL (0-15) Sets the C filter (Chrominance) strength.
  • Page 20: Lens Adjustment

    LANGUAGE LANGUAGE select between: English, Japanese, German, French, Russian, Portuguese & Spanish. CAMERA RESET CAMERA RESET - Returns the camera to the factory default settings. SAVE ALL SAVE ALL - Saves all the changes made in the menu. EXIT EXIT – Exits the menu and does not save changes made. LENS ADJUSTMENT Lens 4 ~ 9mm...
  • Page 21: Heater Installation (Optional Part)

    HEATER INSTALLATION (optional part) As standard the VVRD will work down to -10 C without the heater being fitted. If the heater is fitted the VVRD will work down to -20 C (please note that the heater does not come with the VVRD and needs to be purchased separately). 1 –...
  • Page 22: Specifications

    SPECIFICATIONS MODEL DNLED Resolution 700TVL (colour and monochrome) 1/3″ SONY EXview HAD CCD II Image sensor Total pixels 1028(H) x 596(V) Effective pixels 976(H) x 582(v) Scanning system 2:1 Interlace Scanning frequency PAL: 15.625KHz(H) x 50Hz(V) Sync. system Internal / Line lock Electronic shutter 1/50~1 / 10,000 sec Colour 0.32Lux @...
  • Page 23: Dimensions

    DIMENSIONS...
  • Page 24 MEMO Norbain Ltd, 210 Wharfedale Road, IQ Winnersh, Wokingham, Berkshire RG41 5TP United Kingdom Manual version 1.2 (This manual is subject to change without notice)
