Data Array Parameters

4
Data Arrays are "protocol neutral" data buffers for storage of data to be passed between protocols. It is
necessary to declare the data format of each of the Data Arrays to facilitate correct storage of the relevant
data.
Section Title
Data_Arrays
Column Title Function
Data_Array_Name Provide name for Data Array.
Provide data format. Each Data Array can only take
Data_Format
on one format.
Number of Data Objects. Must be larger than the
Data_Array_Length data storage area required by the Map Descriptors
for the data being placed in this array.
Example
// Data Arrays
Data_Arrays
Data_Array_Name, , Data_Format,
DA_Service_Data , UInt32
DA_Oper_Mode , UInt16
DA_Oper_Data , UInt16
, Data_Array_Length
, 38
, 3
, 5
Gardner Denver Driver Manual
Configuring the FieldServer
Legal Values
Up to 15 alphanumeric
characters
Float, Bit, Byte, Uint16,
Uint32, Sint16, Sint32
1-10000
