5.3

Client Side Map Descriptor Parameters

5.3.1

FieldServer Specific Map Descriptor Parameters

Column Title
Map_Descriptor_Name
Data_Array_Name
Data_Array_Offset
Function
5.3.2

Driver Related Map Descriptor Parameters

Column Title Function
Node_Name Name of Node to fetch data from.
Gar_Cmd Data poll commands.
Data fields in a data poll command response
message. Can be used to poll for all or
Gar_Data*
specific data or just isolate specific items in
an "All" poll.
5.3.3

Timing Parameters

Column Title Function
Rate at which data is polled. Note that the Poll_Delay Connection
Scan_Interval*
parameter affects the effective scan interval.
Function
Name of this Map Descriptor.
Name of Data Array where data is to
be stored in the FieldServer.
Starting location in Data Array.
Function of Client Map Descriptor.
Gardner Denver Driver Manual
Configuring the FieldServer
Legal Values
Up to 32 alphanumeric characters
One of the Data Array names from
Section 4
0 to (Data_Array_Length-1) as
specified in Section 4
RDBC, Passive_Client
Legal Values
One of the node names specified in
"Client Node Descriptor" above
Service_Data, Operating_Mode,
Operating_Data
Service_Data:
All, Advisories, Shutdown_codes,
Hourmeter_shutdown,
Hourmeter_total, Hourmeter_loaded,
Hourmeter_temp, Hourmeter_tmp_st,
Last_maint_A, Last_maint_B, Oilage
Operating_Mode:
All, Oper_mode, Seq_number,
Oper_state
Operating_Mode:
All, System_pressure,
Filter_pressure, Discharge_temp,
Reservoir_temp, Motor_current
Legal Values
≥0.1s, 0.1s
9
