Mounting
5
Mounting
You can flexibly mount the DHC Basic IO Box on walls using the
supplied screws and plugs. To do so, proceed as follows:
1.
Select a suitable mounting location close to your heat-
ing system.
Make sure that no electricity or similar lines run in the
wall at this location!
2.
Unscrew both lower screws of the cover (B) with an
appropriate screwdriver and remove it (see figure 2+3).
3.
Use a pen to mark the positions of the four screw holes
on the wall (see figure 4).
4.
Use an appropriate drill to make the 5 mm holes as
illustrated.
5.
Use the screws and plugs supplied to fix the DHC Ba-
sic IO Box.
10
