6.3
Connections to the indoor unit
Terminal
L
N
PE
OUT1
OUT2
For further information regarding the connections, see
the DHC Application Guide.
L
L
N
N
PE
PE
L▲
1▼
2▼
1▼
OUT1
OUT2
Connection to
Phase conductor
Neutral conductor
Protective earthing conductor
Thermo ON for underfloor
heating
Thermo ON for thermostatic
radiator valves
Start-up
L▲
15
