- Page 1 OPERATION MANUAL AND PARTS LIST 7660.002 ROUND ROD MILLING MACHINE WARNING: 1.Read this operation manual carefully before operation 2.Keep this manual for future reference...
-
Page 2: Specifications
WOOD RATTAN WORKING MACHINE AUTOMATIC ROUND RATTAN AND ROUND ROD MILLING MACHINE 7660.002 The is a precise WOOD RATTAN WORKING MACHINE AUTOMATIC ROUND RATTAN AND ROUND ROD MILLING MACHINE. We believe that if you operate it normally and make a good maintenance periodically, the machine will stay in a perfect condition. -
Page 3: Operation Steps
2. The cutter head is equipped with a stabilizer featuring no chips blocking in stabilizer guide way and effectively reduces the noise level of this machine during operation. 3. There are four rollers for input and output, therefore, any material can be conveyed smoothly. - Page 4 2. Before operation, please check and adjust positions of support bracket for work-piece. When height of work-piece support is inappropriate, loose the handle and fix the support bracket. Fig 1 shown after adjustment is completed. Fig 1...
- Page 5 3. To select the correct feed wheel to install and fix: loose the nuts and wind- up after completed changing of feed wheel. (for the switch side with nuts of left-clockwise & right-counter clockwise thread) Fig 2. Fig 2 4. Even edge tool correct regulation means that as shown in Figure 3. Fig 3...
- Page 6 5. To adjust hand wheel according to sizes of work-piece: adjust spring nuts. See Fig 4. Fig 4 6. There are 4 variable speeds, to select the correct speed， depends on the quality, hard or soft and sizes of work-piece. Fig 5 7.
- Page 7 Φ 12-φ 17 φ 28-φ 42 φ 43-φ 60 φ 18-φ 27 φ 9-φ 11 Fig 6（圖 6） MAINTENANECE: 1. Do not open the tool guard or put in anything while the machine is in operation. Always keep away from the dust exhaust port. Do not put in band or open the tool guard when machine in operating，...
- Page 8 ROD MILLING MACHINE Description QUANTITY Lower Base Support of Motor Seat Hexagon Screw Flat Washer Hexagon screw Seat of Motor & Transmission Seat of Motor Hexagon screw Set plate Hexagon Screw Hexagon Screw Flat Washer Left Column Hexagon screw Flat Washer Hexagon screw Flat Washer...
- Page 9 32-1 Pulley Spring Washer Hexagon screw Transmission Rod Head Transmission Rod Handle Hexagon screw Seat of Reducer Reducer Spring Washer Hexagon screw Pulley Round Head Screw Hexagon screw Guard Round Head Screw...
- Page 10 ROD MILLING MACHINE Upper Base Gear Gear Gear Socket Head Screw Chain Drum Socket Head Screw Flat Washer Hexagon screw Hexagon screw Chain Drum Gear Coupler Hexagon screw Chain Drum Snap Ring Idle Gear Shaft Idle Gear Support Flat Washer Flat Washer Hexagon screw Support of Hanging Hook...
- Page 11 Hand Wheel Seat Bushing Hexagon screw Handle wheel Movable Handle Gear Box Seat Hexagon screw Bearing Dual Needle Roller Bearing Gear Box Bottom Bearing Lower Gear Shaft Upper Gear Shaft Bearing Bearing Bushing Gear Box Covet Bearing Socket Head Screw Bearing Locking Cover Bushing Feet Wheel of R-Shape...
- Page 12 ROD MILLING MACHINE Spindle Seat Spindle Cover Spindle Bearing Bearing Locking Ring Spindle Read Cover Hexagon screw Guide Tube Bushing Steady Controller Guide Tube Hexagon screw Grease Nipple Socket Head Screw Hexagon screw Flat Washer Bearing Spindle Front Cover Flat Knife Flat Washer Hexagon screw Hexagon screw...
