max 5 x 3.5
General Information
PLEASE READ THROUGH BEFORE BEGINNING ASSEMBLY.
IMPORTANT: Check boxes for Contents Listed
Check inside of parts as some parts are packaged
inside of others
In the event of missing, damaged or defective parts
please call our customer service dept. at 1-877-258-6020
When assembling components, place on a clean, flat
non-abrasive surface to avoid scratches
Tools Required
... Battery or Electric Drill
... Hammer or Rubber Mallet
... PVC, Super, or Crazy Glue
with #2 phillips bit
(recommended)
Cambridge Trellis
11172
Model#
Part #
1
2" sq. x 74" Left Post
2
2" sq. x 74" Right Post
3
⅞ x 3 x 27½" Top/Bottom Cross Rail
4
¼ x 1½ x 63" Vertical Slat
5
¼ x 1½ x 27½" Horizontal Slat
6
⅞ x 1½ x 27½" Bent Top
7
Hardware Bag
2" sq." Post Cap
1¼" Painted Screw
Trellis Ground Anchor Kit
16" Steel Ground Anchor (L-Shaped)
#8 - 1" Painted Self Tapping Screw
150 Birch Road
P.O. Box 122
Sheboygan Falls, WI 53085
Assembly Instructions
Description
(includes:)
(includes:)
1-877-258-6020
www.dura-trel.com
sales@dura-trel.com
Qty
1
1
2
3
6
1
1
2
8
1
2
4
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Dura Trel Cambridge Trellis 11172
Summary of Contents for Dura Trel Cambridge Trellis 11172
- Page 1 Cambridge Trellis 11172 Model# Assembly Instructions Part # Description 2" sq. x 74" Left Post max 5 x 3.5 2" sq. x 74" Right Post ⅞ x 3 x 27½" Top/Bottom Cross Rail ¼ x 1½ x 63" Vertical Slat ¼...
- Page 2 Warranty Statement 20 Year Guarantee Please call manufacturer direct with questions concerning missing or defective parts at Toll Free: 877-258-6020. Dura-trel, Inc. products are warranted to be free from manufacturing defects resulting in delaminating, peeling, flaking, corroding, cracking, crazing, or extreme amounts of fading or bleaching causing the PVC to change to its natural color for a period of 20 years from the date of purchase.
- Page 3 Lay out one right post (part 2). Starting at bottom, insert one top/bottom cross rail (part 3) and six horizontal slats (part 4). Slide left post (part 1) over corresponding cross rail and slats. Weave one vertical slat (part 5) through horizontal slats.
- Page 4 Separate tops of post just enough to insert remaining top/bottom cross rail (part 3) and bent trellis top (part Using four 1¼” screws per post, screw together trellis. Be sure that all parts are fully inserted into posts before securing. Instruction Text Using PVC, super or crazy glue;...
- Page 5 Cambridge Trellis 11172 2" sq. x 74" CBT Left Post 1.00 2" sq. x 74" CBT Right Post 1.00 ⅞ x 3 x 27½" CB Top/Bottom 2.00 ¼ x 1½ x 63" Slat 3.00 ¼ x 1½ x 27½" Slat 6.00 ⅞...
