Dura Trel CAMELOT PLANTER ARBOR SEAT Assembly Instructions

TOOLS NEEDED

Drill with #2 Phillips Bit or
Phillips Screwdriver
Super or Crazy Glue

SEAT ASSEMBLY

(Refer to Drawing 1)
On a clean flat surface lay the three 1 ½ x 5 ½ x 54" rails with pilot holes facing up. Set the 14"
brackets over rail lining up brackets with the pilot holes. Fasten loosely with ¾" screws.
Apply household glue to inside of the 7/8 x 1 ½" end caps and slide onto the ends of 7/8 x 1 ½ x
16 ½" center brace. Set the 7 /8 x 1 ½ x 16 ½" center brace in place over pilot holes, fasten with
the 2" screws.
Apply glue to the inside edges of the 7/8 x 1 ½ x 17" end cap and push end cap onto edge of seat
(do not slide from end), sliding the end cap under bracket as you do. Tighten all the ¾" screws on
brackets.
Seat is now ready to set between the two large planter boxes.
If you encounter missing or defective parts, please contact manufacturer direct at
Dura-Trel Inc. ~ PO Box 122, Sheboygan Falls, WI 53085 ~ Toll Free 877-258-6020
C
AMELOT
assembly INSTRUCTIONS
toll free # below.
P A
LANTER
Note: Camelot Planter Arbor
sold separately.
S
RBOR EAT
