max 5 x 3.5
General Information
PLEASE READ THROUGH BEFORE BEGINNING ASSEMBLY.
IMPORTANT: Check boxes for Contents Listed
Check inside of parts as some parts are packaged
inside of others
In the event of missing, damaged or defective parts
please call our customer service dept. at 1-877-258-6020
When assembling components, place on a clean, flat
non-abrasive surface to avoid scratches
Tools Required
... Battery or Electric Drill
... Tape Measure
... Hammer or Rubber Mallet
with #2 phillips bit
(recommended)
Wellington Arbor
11179
Model#
Part #
1
2" sq. x 84" Left Post
2
2" sq. x 84" Right Post
3
⅞ x 1½ x 27½" Outer Cross Rail
4
⅞ x 1½ x 27½" Inner Cross Rail
5
⅞ x 1½ x 27½" Middle Cross Rail
6
1 x 1 x 26½" Vertical Rail
7
1 x 1 x 16¾" Vertical Rail
8
1 x 1 x 13" Vertical Rail
9
1½ x 4 x 72" Arbor Top Rail
10
⅞ x 1½ x 41" Arbor Top Cross Rail
11
⅞ x 1½ x 18" Corner Brace
12
5 ⅜" Arbor Top End Cap
13
Hardware Bag
2" sq." Post Cap
⅞ x 1½" End Cap
1¼" Painted Screw
¾" Painted Screw
Super Glue Tube
14
Arbor Ground Anchor Kit
16" Steel Ground Anchor (L-Shaped)
#8 - 1" Painted Self Tapping Screw
150 Birch Road
P.O. Box 122
Sheboygan Falls, WI 53085
Assembly Instructions
Description
(includes:)
(includes:)
1-877-258-6020
www.dura-trel.com
sales@dura-trel.com
Qty
2
2
4
8
4
8
8
4
2
8
4
4
1
4
16
28
16
1
1
4
8
1
Advertisement
Related Manuals for Dura Trel Wellington Arbor 11179
Summary of Contents for Dura Trel Wellington Arbor 11179
- Page 1 Wellington Arbor 11179 Model# Assembly Instructions Part # Description 2" sq. x 84" Left Post max 5 x 3.5 2" sq. x 84" Right Post ⅞ x 1½ x 27½" Outer Cross Rail ⅞ x 1½ x 27½" Inner Cross Rail ⅞...
- Page 2 Warranty Statement 20 Year Guarantee Please call manufacturer direct with questions concerning missing or defective parts at Toll Free: 877-258-6020. Dura-trel, Inc. products are warranted to be free from manufacturing defects resulting in delaminating, peeling, flaking, corroding, cracking, crazing, or extreme amounts of fading or bleaching causing the PVC to change to its natural color for a period of 20 years from the date of purchase.
- Page 3 Starting at bottom of one 84" left post (part 1), insert one 27½" outer cross rail (part 3) and two 27½" inner cross rails (part 4). When inserting two inner cross rails insert sides with four routed holes facing each other.
- Page 4 Insert two 27½" middle cross rails (part 5) into remaining routed holes in side of post, inserting free ends of 26½" vertical rails into middle cross rail. Insert four 16¾" vertical rails (part 7) into remaining holes in inside cross rails. Insert two 13" vertical rails (part 8) into remaining holes in middle cross rails. Insert free ends of cross rails into one 84"...
- Page 5 Insert two 18" corner braces (part 11) into each 72" arbor top (part 9). Slide ends of arbor top rail through holes at top of post, inserting corner braces into posts. Measure 9 inches from tips of arbor top rails and slide posts so outside of post in 9 inches from end of arbor top rails.
- Page 6 Wellington Arbor 11179 2" sq. x 88" WLA Left Post 2.00 2" sq. x 88" WLA Right Post 2.00 ⅞ x 1½ x 27½" WL Outer Rai 4.00 ⅞ x 1½ x 27½" WL Inner Ra 8.00 ⅞ x 1½ x 27½" WL Middle Ra 4.00 1 x 1 x 26½"...
