General Information
PLEASE READ THROUGH BEFORE BEGINNING ASSEMBLY.
IMPORTANT: Check boxes for Contents Listed
Check inside of parts as some parts are packaged
inside of others
In the event of missing, damaged or defective parts
please call our customer service dept. at 1-877-258-6020
When assembling components, place on a clean, flat
non-abrasive surface to avoid scratches
Tools Required
... Battery or Electric Drill
with #2 phillips bit
Berkshire Potting Bench
11200
Model#
Part #
1
4 sq. x 66" Back Left Post
2
4 sq. x 66" Back Right Post
3
4 sq. x 38" Front Left Post
4
4 sq. x 38" Front Right Post
5
1½ x 4 x 51½" Table Rail
6
1½ x 4 x 51½" Shelf Rail
7
1½ x 4 x 22" Side Rail
8
¼ x 1½ x 25" Back Panel Slat
9
⅞ x 1½ x 51½" Back Panel Top/Bottom Rail
10
⅞ x 1½ x 51½" Back Panel Center Rail
11
⅞ x 1½ x 51½" Back Panel Center Shelf Rail
12
⅞ x 1½ x 51½" Back Panel Bent Top
13
⅞ x 1½ x 22" Table Top Brace
14
⅞ x 3 x 24½" Table/Shelf Rail
15
1½ x 5½ x 43" Table Top Rail
16
1½ x 5½ x 43" Shelf Rail
17
22" Table Top End Cap
18
5½" Shelf End Cap
19
4" sq. Flat Post Cap
20
Hardware Bag
7" Shelf Hook
1¼" Painted Screw
¾" Painted Screw
Super Glue Tube
150 Birch Road
P.O. Box 122
Sheboygan Falls, WI 53085
Assembly Instructions
Description
(includes:)
1-877-258-6020
www.dura-trel.com
sales@dura-trel.com
Qty
1
1
1
1
2
2
4
8
2
3
1
1
2
14
4
1
2
2
4
1
2
16
36
1
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dura Trel Berkshire 11200
Summary of Contents for Dura Trel Berkshire 11200
- Page 1 Berkshire Potting Bench 11200 Model# Assembly Instructions Part # Description 4 sq. x 66" Back Left Post max 5 x 3.5 4 sq. x 66" Back Right Post 4 sq. x 38" Front Left Post 4 sq. x 38" Front Right Post 1½...
- Page 2 Warranty Statement 20 Year Guarantee Please call manufacturer direct with questions concerning missing or defective parts at Toll Free: 877-258-6020. Dura-trel, Inc. products are warranted to be free from manufacturing defects resulting in delaminating, peeling, flaking, corroding, cracking, crazing, or extreme amounts of fading or bleaching causing the PVC to change to its natural color for a period of 20 years from the date of purchase.
- Page 3 Starting at bottom of 66" back left post (part 1), insert one 51½" shelf rail (part 6) , one 51½" table rail (part 5), one 51½" back panel top/bottom rail (part 9), three back panel center rails (part 10) and one back panel center shelf rail (part 11).
- Page 4 Insert one 51½" table rail (part 5) into 38" front right post (part 4). Insert one 51½" shelf rail (part 6) into 38" front right post. Insert free ends of table and shelf rail into 38" back left post (part 3). Using four ¾" screws per post, screw together potting bench front panel.
- Page 5 Insert four 22" side rails (part 7) into posts of potting bench pack panel (from page 3). Insert three 24½" table/shelf rails into table rail of back panel. Insert eleven table/shelf rails into shelf rail of back panel. Insert free ends of side rails and table/shelf rails into corresponding holes of potting bench front panel (from page 4).
- Page 6 Apply glue to inside edges of 5½" shelf end cap. Press end cap onto ends of 43" shelf rail (part 16) (DO NOT slide from end). Insert two 7" shelf hooks from hardware packet into pre-drilled holes and place shelf on top of hooks.
- Page 7 Berkshire Potting Bench 11200 4" sq. x 66" BPtB Back Lt Post 1.00 4" sq. x 66" BPtB Back Rt Post 1.00 4" sq. x 38" PtB Front Lt Post 1.00 4" sq. x 38" PtB Front Rt Post 1.00 1½...
