TOOLS NEEDED
Drill with #2 Phillips Bit or
Phillips Screwdriver
Super or Crazy Glue (optional)
SEAT ASSEMBLY
(Refer to Drawing 1)
Lay the two 48" seat rails on clean, flat surface with pilot holes facing up. Set the brackets over
pilot holes in rails, with the flanged side of the bracket toward center of seat. Fasten brackets to
seat rails with ¾" screws. Slide end caps over ends of seat, end caps will slide between bracket and
rails. You may apply household glue to inside of end cap if needed.
Place planter seat between two planter boxes by setting brackets over the edge of both planters.
If you encounter missing or defective parts, please contact manufacturer direct at
Dura-Trel, Inc. ~ PO Box 122, Sheboygan Falls, WI 53085 ~ Toll Free 877-258-6020
#11130 P
ASSEMBLY INSTRUCTIONS
toll free # below.
S
LANTER
EAT
Advertisement
Table of Contents
Related Manuals for Dura Trel 11130
Summary of Contents for Dura Trel 11130
- Page 1 #11130 P LANTER ASSEMBLY INSTRUCTIONS TOOLS NEEDED Drill with #2 Phillips Bit or Phillips Screwdriver Super or Crazy Glue (optional) SEAT ASSEMBLY (Refer to Drawing 1) Lay the two 48” seat rails on clean, flat surface with pilot holes facing up. Set the brackets over pilot holes in rails, with the flanged side of the bracket toward center of seat.
- Page 3 PACKING LIST #11130 lanter PARTS CONTAINED: QTY. PART NO. PART DESCRIPTION 41555-48003W 1½ x 5½ x 48” SEAT RAIL (w/ wood inserts) 4TBCK-08752 8¾” BRACKET 5ECAP-11180 ⅞ x 1½ x 11⅛” END CAP Hardware Bag Includes: 7HDWR-06034 ¾” SCREW PLANTER SEAT INSTRUCTION NOTE: Some parts may be packed inside of others If you encounter missing or defective parts, please contact manufacturer direct at toll free # below.
