Dura Trel Sunburst Trellis 11147/8 Assembly Instructions

General Information
PLEASE READ THROUGH BEFORE BEGINNING ASSEMBLY.
IMPORTANT: Check boxes for Contents Listed
Check inside of parts as some parts are packaged
inside of others
In the event of missing, damaged or defective parts
please call our customer service dept. at 1-877-258-6020
When assembling components, place on a clean, flat
non-abrasive surface to avoid scratches
Tools Required
... Battery or Electric Drill
... PVC, Super, or Crazy Glue
... Hammer or Rubber Mallet
... Straight Blade Screwdriver
with #2 phillips bit
(recommended)
(if combining trellis with planter)
Sunburst Trellis
11147 / 8
Model#
Part #
1 2" sq. x 59½" Left Post
2 2" sq. x 59½" Right Post
3 ⅞ x 3 x 27½" Bottom Cross Rail
4 ⅞ x 3 x 27½" Center Cross Rail
5 ⅞ x 3 x 27½" Top Cross Rail
6 ⅞ x 1½ x 27½" Bent Top Rail
7 24 x 48" Green or White Lattice
8 Hardware Bag
2" sq." Post Cap
1¼" Painted Screw
⅝ x 9½" Tube
⅝ x 11" Tube
9 Trellis Ground Anchor Kit
16" Steel Ground Anchor (L-Shaped)
#8 - 1" Painted Self Tapping Screw
150 Birch Road
P.O. Box 122
Sheboygan Falls, WI 53085
Assembly Instructions
Description
(includes:)
(includes:)
1-877-258-6020
www.dura-trel.com
sales@dura-trel.com
Qty
1
1
1
1
1
1
1
1
2
6
3
2
1
2
4
1
