CHAINTECH CT-7NJS User Manual page 8

AMD Athlon CPU (K7/Thunderbird)
CPU FSB
Model Multiplier Vcore
Speed Frequency
700 700MHz 100
750 100
750MHz
800 800MHz 100
850 850MHz 100
900 100
900MHz
950 950MHz 100
1000 100
1000MHz
1100 1100MHz 100
1200 1200MHz 100
1300 100
1300MHz
1400 1400MHz 100
1000 1000MHz 133
1113 133
1113MHz
1200 133
1200MHz
1333 1333MHz 133
1400 1400MHz 133
AMD Athlon XP CPU (Palomino/Thoroughbred)
CPU FSB
Model Multiplier
Speed Frequency
1500+ 1333MHz 133
1600+ 1400MHz 133
1467MHz
1700+ 133
1800+ 1500MHz 133
1900+ 1600MHz 133
2000+ 1666MHz 133
2100+ 1733MHz 133
2200+ 1800MHz 133
2400+ 1995MHz 133
2128MHz
2600+ 133
2700+ 2158MHz 166
7NJS User's Guide
Chapter 2
L2 Micron
Cache process
7.0 1.70V 256KB 0.18
7.5 1.70V 256KB 0.18
8.0 1.70V 256KB 0.18
8.5 1.70V 256KB 0.18
9.0 1.75V 256KB 0.18
9.5 1.75V 256KB 0.18
10.0 1.75V 256KB 0.18
11.0 1.75V 256KB 0.18
12.0 1.75V 256KB 0.18
13.0 1.75V 256KB 0.18
14.0 1.75V 256KB 0.18
7.5 1.75V 256KB 0.18
8.5 1.75V 256KB 0.18
9.0 1.75V 256KB 0.18
10.0 1.75V 256KB 0.18
10.5 1.75V 256KB 0.18
L2 Micron
Vcore
Cache process
10.0 1.7V 256KB 0.18
10.5 1.7V 256KB 0.18
11.0 1.7/1.6V 256KB 0.18/0.13
11.5 1.7/1.6V 256KB 0.18/0.13
12.0 1.7/1.6V 256KB 0.18/0.13
12.5 1.7/1.6V 256KB 0.18/0.13
13.0 1.7/1.6V 256KB 0.18/0.13
13.5 1.65V 256KB 0.13
15.0 1.65V 256KB 0.13
16.0 1.65V 256KB 0.13
13.0 1.65V 256KB 0.13
Chapter 2
2.3 Main Memory Configuration
The DDR SDRAM memory system consists three banks, each bank supports
up to 1GB of memory.
DDR SDRAM Specifications
Memory Frequency
100 MHz
133 MHz
166 MHz
200 MHz
DIMM type: 2.5V, unbuffered 184 pin 64/128/256/512-bit DDR SDRAM
Module size: Single/double-sided 64/128/256/512MB/1GB
Parity:
Location
DDR 1
DDR 2
DDR 3
Note:
For maximized Dual-channel (128-bit) result, you must install one of your
two memory modules on DDR3.
Memory compatibility test please refer to Appendix DDR Memory Test.
9 10
Internal System BUS Frequency
200 MHz
266 MHz
333 MHz
400 MHz
Either parity or non-parity
64 MB 128 MB 256 MB
X X X
X X X
X X X
7NJS User's Guide
512 MB 1.0 GB
X X
X X
X X
