U4 refers to 66MB/sec transfers, etc.)
FastBuild (tm) Utility 1.xx (c) 1995-2000 Promise Technology, Inc.
[ View Drive Assignments ]
Channel:ID Drive Model
1 : Master QUANTUMCR8.4A
2 : Master QUANTUMCR8.4A
[ Keys Available ]
[↑] Up [↓] Down [ESC] Exit Mode (D=DMA, U=UDMA)
How FastTrak 376 Orders Arrays
During startup, the disk arrays on the FastTrak 376 are recognized in this order:
1) The array set to bootable in the FastBuild ™ Setup, and 2) the Array number
(i.e. Array 0, Array 1...). This would be involved in determining which drive
letters will be assigned to each disk array.
How FastTrak 376 Saves Array Information
All disk array data is saved into the reserved sector on each array member.
Promise suggests that users record their disk array information for future
reference.
Another feature of the FastTrak 376 disk array system is to recognize drive
members even if drives are moved between different FastTrak 376 controller
connectors. Since each drive's array data identifies itself to the array, it is
possible to move or swap drives without modifying the array setup. This is
valuable when adding drives, or during a rebuild.

Deleting An Array

The Delete Array [4] Menu option allows for deletion of disk array
assignments. This is not the same as deleting data from the drives themselves. If
you delete an array by accident (and before it has been used again), the array can
normally be recovered by defining the array identically as the deleted array.
WARNING:
Deleting an existing disk array could result in its data loss. Make sure
to record all array information including the array type, the disk members, and stripe
block size in case you wish to undo a deletion.
Appendix
Serial ATA/IDE RAID
Capacity(MB) Assignment Mode
8063 Array 1 U5
8063 Array 1 U5
Serial ATA/IDE RAID
FastBuild (tm) Utility 2.xx (c) 2002-2005 Promise Technology, Inc.
Array No
Array 1
Array 2
Array 3
Array 4
1. To delete an array, highlight the Array you wish to delete and press the [Del]
key.
2. The View Array Definition menu will appear (see below) showing which
drives are assigned to this array.
FastBuild (tm) Utility 2.xx (c) 2002-2005 Promise Technology, Inc.
Array No
Array 1
Stripe Block: 64 KB
Channel:ID Drive Model
1 : Master
2 : Master
3. Confirm yes to the following warning message with the [Ctrl-Y] key to
continue array deletion:
Are you sure you want to delete this array?
Press Ctrl-Y to Delete, others to Abort
4. After deleting the array, you should create a new array using Auto Setup or
the Define Array menu from the FastBuild Main Menu.
83 84
[ Delete Array Menu ]
RAID Mode Total Drv Capacity(MB)
Stripe 2 16126
—— —— ——
—— —— ——
—— —— ——
[ Keys Available ]
[↑] Up [↓] Down [ESC] Exit [Del] Delete
[ Define Array Menu ]
RAID Mode Total Drv Capacity(MB)
—— —— ——
[ Drive Assignments ]
Capacity (MB)
QUANTUMCR8.4A 8063
QUANTUMCR8.4A 8063
Appendix
Status
Functional
——
——
——
Status
——
Assignment
Y
