Chapter 1 Introduction
1.1 Product Specifications
Processor
- Supports AMD Socket A Duron/Athlon/Athlon XP CPU
- System clock supports 200/266/333MHz
Chipset
- NVIDIA nForce2 SPP + MCP-T
Main Memory
- Three 184 pin DDR DIMMs up to 3GB
-
Supports PC1600/2100/2700/3200 Dual-Channel DDR modules
Expansion Slots
- One universal-AGP slot for both 4X/8X AGP
- Five 32-Bit PCI slots (v2.2 compatible)
- One ACR slot supports modem, audio, Dolby AC3 Decoder or IEEE1394
adaptor
On-board audio CMedia 8738
- Full-duplex operation for simultaneous recording and playback.
- 6 Channel speaker audio supports.
-
Embedded 32ohm 5w earphone amplifier.
-
Supports MIDI and dual game ports.
-
32 Voice HRTF-3D positional audio, CRL-3D supports MS Direct.
- Sound3D, Aureal A3D and Creative EAX APIs.
- Supports SPDIF.
Ultra DMA-66/100/133 PCI IDE Controller
- Supports two IDE ports up to 4 ATAPI devices
- Supports PIO Mode 4 up to 16.6MBps, Multi Mode 4 up to 66MBps, Multi
Word Mode 5 up to 100MBps and Multi Word Mode 6 up to 133MBps with
Bus Mastering.
- Bus-Mastering software drivers for all common multi-tasking operating
systems
On-board Serial ATA Controller
- Promise PDC20376 Serial ATA controller supports extra two Serial ATA
ports and one UltraDMA-100/133 IDE port with RAID 0/1.
USB 2.0/1.1 Host Controller
- One EHCI USB 2.0 Controller and 2 UHCI USB 1.1 Controllers
- Support total 6 USB 2.0 Ports (USB1.1 compatible).
-
Support USB 2.0 High-Speed Device @480 Mb/s Transfer Rates.
7NJS User's Guide
Chapter 1 Chapter 1
On board Super I/O Controller
- ITE 8712 LPC I/O with system monitors hardware.
- Two UARTs support serial ports and IR function (up to 115.2Kbps) for
HPSIR and ASKIR.
- One SPP/ECP/EPP parallel port.
- One floppy disk drive connector supports up to 2.88MB.
Integrates smart card reader function and interface, to be qualified for meeting
PC/SC standard.
Fast Ethernet/Home Networking Controller with MII Interface
- Support 10/100Mb Fast Ethernet or 1/10Mb HomePNA 2.0 with External
PHY.
Embedded system monitoring
- 8 external voltage inputs
- 2 temperatures sensing for CPU and system.
- 2 Fan speed (CPU and system) monitoring.
Boot-Block Flash ROM
- Award system BIOS support PnP, APM, DMI, ACPI, & Multi-device.
1.2 Package Contents
This product comes with the following components:
1.
2.
3.
4.
5.
6.
7.
1 2
Motherboard.
I / O Panel
Round Cable:
Include:
-
IDE Cable (60cm)
-
Floppy Cable (60cm)
Serial ATA cable (60cm)
Audio KIT:
Include:
-
SPDIF kit
-
6channel kit
-
Fiber Optical Cable
CBOX2™ Package
Include:
- 5-1/4" CBOX™2
- USB 10-pin Cable
-
Front Audio 10-pin Cable
-
80-Port 10-pin Cable
-
IEEE-1394 8-pin Cable
IEEE-1394 ACR daughter card
7NJS User's Guide
x 1
x 1
x 2
x 1
x 2
x 1
x 1
x 1
x 1
x 2
x 1
x 1
x 1
x 1
