- Page 1 Slimdrive SL NT EN Additional installation instructions Slimdrive SL NT-FR 141629-01...
-
Page 2: Table Of Contents
Slimdrive SL NT GGS / Slimdrive SL NT-FR GGS Table of contents Symbols and illustrations .............................3 Product liability ................................3 Safety notices ................................3 Intended use ........................................3 Safety notices ........................................3 Safety-conscious working ....................................4 Inspection of the installed system ................................4 Environmentally conscious working ................................4 Installation .................................5... -
Page 3: Symbols And Illustrations
à in entrances and interior areas of pedestrian traffic in commercial plants and public areas. à The Slimdrive SL NT GGS and the Slimdrive SL NT-FR GGS may not be used as a fire or smoke protection door. à The Slimdrive SL NT-FR GGS is approved for use in escape and rescue routes. -
Page 4: Safety-Conscious Working
Safety notices Slimdrive SL NT GGS / Slimdrive SL NT-FR GGS à Observe the latest versions of directives, standards and country-specific regulations, in particular: à VDE 0100, Part 610 "Installing Electrical Power Systems with Nominal Voltages up to 1000 V"... -
Page 5: Installation
Slimdrive SL NT GGS / Slimdrive SL NT-FR GGS Installation Installation Mounting the moving leaf Mount the leaf suspensions (1). Tighten the screws (2) with 11–13 Nm. Glue the transparent bumpers (3) to the top and bottom of the moving leaves. -
Page 6: Install The Floor Guide (Version With No Side Part)
Installation Slimdrive SL NT GGS / Slimdrive SL NT-FR GGS Install the floor guide (version with no side part) Ensure that the bonding surface in the floor guide (4) is clean and free of grease. Remove the foil (3) from the felt (1) and (2). -
Page 7: Install The Floor Guide And Side Parts
Slimdrive SL NT GGS / Slimdrive SL NT-FR GGS Installation Install the floor guide and side parts 4.3.1 Mounting the floor guide Ensure that the bonding surface is clean and free of grease. Glue the felt (1) to the floor guide bracket (2). - Page 8 Installation Slimdrive SL NT GGS / Slimdrive SL NT-FR GGS 4.3.2 Mounting side parts Preparation Screw the side part blocks (1) over the recesses (2) of the side part (3) onto the track. Glue the self-adhesive rubber strips (4) onto the track under the side part blocks (1).
- Page 9 Slimdrive SL NT GGS / Slimdrive SL NT-FR GGS Installation Slide 2 glazing gaskets (7) between the side part rail (6) and the side part. Moving leaf side Screw the cover caps (9) onto the side part rails.
- Page 10 Installation Slimdrive SL NT GGS / Slimdrive SL NT-FR GGS 4.3.3 Making a recess in the side plates Carry out the work on site to ensure a good optical impression. If necessary, make recesses in the side panels (1) for the side parts and/or moving leaves (see arrow).
- Page 11 Slimdrive SL NT GGS / Slimdrive SL NT-FR GGS Installation...
- Page 12 E-Mail: danmark.se@geze.com Tel. +49 (0) 7152 203 594 www.geze.at www.geze.hu www.geze.dk E-Mail: leonberg.de@geze.com Baltic States Iberia Singapore GEZE GmbH Baltic States office GEZE Iberia S.R.L. GEZE (Asia Pacific) Pte, Ltd. GEZE GmbH E-Mail: office-latvia@geze.com E-Mail: info@geze.es E-Mail: gezesea@geze.com.sg Niederlassung Süd-Ost www.geze.com www.geze.es...
