Slimdrive EMD
EN Installation and service instructions
Invers
138676-05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Slimdrive EMD Invers and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GEZE Slimdrive EMD Invers

Summary of Contents for GEZE Slimdrive EMD Invers

  • Page 1 Slimdrive EMD EN Installation and service instructions Invers 138676-05...

  • Page 2: Table Of Contents

    Environmentally conscious working .................................6 Overview..................................6 Tools and aids ........................................6 Consumables ........................................6 Supplied by GEZE and completeness .......................7 The Slimdrive EMD Invers door drive with roller guide rail or link arm ..................7 Accessories (optional) .....................................7 4.2.1 Mechanical accessories ....................................7 4.2.2 Electrical accessories .......................................7 Transportation and storage ..........................7...
  • Page 3 Entries on the identification plate ................................38 Commissioning tests ............................40 Service mode ................................. 40 Service and maintenance ..........................40 13.1 Dangers during mechanical service ............................... 40 13.2 Maintenance work ......................................41 13.3 Electrical service......................................41 13.4 Electrical faults........................................ 42 Installation checklist Slimdrive EMD Invers ....................42...

  • Page 4: Introduction

    Introduction Slimdrive EMD Invers Introduction 1. 1 Symbols and illustrations Warning notices In these instructions, warnings are used to warn against material damage and injuries. Always read and observe these warning notices. Observe all measures marked with the warning symbol and warning word .

  • Page 5: Fundamental Safety Precautions

    à The country-specific laws and regulations are to be observed during safety-related tests. à If unauthorised changes are made to the system, GEZE cannot be held liable in any way whatsoever for any resulting damage, and the statement of approval for use in escape and rescue routes is no longer valid.

  • Page 6: Safety-Conscious Working

    Overview Slimdrive EMD Invers Safety-conscious working à Secure workplace against unauthorised entry. à Watch the swivelling range of long system parts. à Never carry out work with a high safety risk (e.g. installing the drive or cover) while alone. à Secure the cover/drive panels against falling.

  • Page 7: Supplied By Geze And Completeness

    Additional optional accessories possible. Transportation and storage à The Slimdrive EMD Invers door drive is not built for hard knocks or for falling from a height. Do not throw, do not drop. à Storage temperatures under -30 °C and above +60 °C can result in damage to the device.

  • Page 8: Product Description

    à is a swing door drive with fully automatic operation activated by sensors or push buttons. à operates electrically during opening and closing. Use of 2x Slimdrive EMD Invers is possible for 2-leaf doors. In the case of a power failure or triggered alarm it opens mechanically.

  • Page 9: Mechanical Data

    Slimdrive EMD Invers Product description 6. 1 .2 Mechanical data Dimensions (H x D x L): 70 mm × 122 mm × 650 mm Max. ambient temperature range: –15 °C … +50 °C Drive mass: approx. 9 kg 6. 1 .3...

  • Page 10: Link Arm

    Product description Slimdrive EMD Invers 6.2.3 Link arm Standard link arm: for reveal depth SD: à 0–100 mm à 100–200 mm à 200–300 mm à 300–400 mm 6.2.4 Mounting plate for drives (option) A mounting plate may be necessary, depending on the installation situation.

  • Page 11: Installation, Types Of Door Stop

    à With outward opening exterior doors the type of installation transom installation opposite hinge side with link arm is recommended for exterior doors (wind load). The Slimdrive EMD Invers allows the following types of door, each for doors DIN left and DIN right: Type of installation...
  • Page 12 Without integrated opening restrictor. An integrated opening restrictor can influence the door opening angle The max. door opening angle can only be achieved with an alternative lever from the lever range from GEZE GmbH. The max. standard opening angle is 100°, see table in chapter 8.6.1...

  • Page 13: Preparing Installation

    Slimdrive EMD Invers Preparing installation Preparing installation 7. 1 General installation information à Observe all the instructions. Incorrect installation can result in serious injuries. à The specified ambient temperature range at the installation location of the drive must be observed.

  • Page 14: Fitting Dimensions For The Installation Types

    Preparing installation Slimdrive EMD Invers Fitting dimensions for the installation types 7.2. 1 Transom installation hinge side with roller guide rail (single leaf) à Hole pattern DIN left and DIN right reversed. Note the separate installation instructions when using a sensor roller guide rail.
  • Page 15 Mount the motor (10) and trans- former facing the hinge side. Space requirement and attachment for roller guide rail Space requirement for Slimdrive EMD Invers Dimensional reference top edge door profile (= top edge roller guide rail) Space requirement for roller guide rail...

  • Page 16: Transom Installation Opposite Hinge Side With Roller Guide Rail (Single Leaf)

    Preparing installation Slimdrive EMD Invers 7.2.2 Transom installation opposite hinge side with roller guide rail (single leaf) à With outward opening exterior doors the type of installation transom installation opposite hinge side with link arm is recommended for exterior doors (wind load).
  • Page 17 Fitting alignment Mount control unit (10) facing the hinge side. Space requirement and attachment for roller guide rail Space requirement for Slimdrive EMD Invers Dimensional reference lower edge frame (lintel) Attachment of roller guide rail with M5 screws or chipboard screws Dimension Y: Upper edge of the roller guide rail –...

  • Page 18: Transom Installation Opposite Hinge Side With Link Arm (Single Leaf)

    Preparing installation Slimdrive EMD Invers 7.2.3 Transom installation opposite hinge side with link arm (single leaf) à Hole pattern DIN left and DIN right reversed. Attachment with mounting plate Direct attachment Ø 15-20 mm Ø 15-20 mm Ø 15-20 mm Ø...
  • Page 19 Fitting alignment Mount control unit (11) facing the hinge side. Space requirement and attachment for roller guide rail Space requirement for Slimdrive EMD Invers Dimensional reference lower edge frame (lintel) Attachment of link arm with M5 screws or chipboard screws...

  • Page 20: Door Leaf Installation Hinge Side (Single Leaf)

    Preparing installation Slimdrive EMD Invers 7.2.4 Door leaf installation hinge side (single leaf) à Hole pattern DIN left and DIN right reversed. Check whether the door can be opened wide enough. Connect all the cables with door transmission to the junction boxes (concealed/surface mounting).
  • Page 21 Space requirement and attachment for roller guide rail Space requirement for roller guide rail Dimensional reference top edge door profile Space requirement for Slimdrive EMD Invers Attachment of roller guide rail with M5 screws or chipboard screws Dimension Y: Lower edge of the roller guide rail –...

  • Page 22: Transom Installation Hinge Side With Roller Guide Rail (Double Leaf)

    Transom installation hinge side with roller guide rail (double leaf) For vertical clearance measurement see chapter 7.2.1. Use 2× fitting template as with single-leaf version. Fastening 2x Slimdrive EMD Invers with intermediate mounting plate Fastening 2x Slimdrive EMD Invers with continuous mounting plate See above for missing dimensions...

  • Page 23: Transom Installation Opposite Hinge Side With Roller Guide Rail (Double Leaf)

    à With outward opening exterior doors the type of installation transom installation opposite hinge side with link arm is recommended for exterior doors (wind load). Use fitting template as with single-leaf version. Fastening 2x Slimdrive EMD Invers with intermediate mounting plate Fastening 2x Slimdrive EMD Invers with continuous mounting plate See above for missing dimensions...

  • Page 24: Transom Installation Opposite Hinge Side With Link Arm (Double Leaf)

    Transom installation opposite hinge side with link arm (double leaf) For vertical clearance measurement see chapter 7.2.3. Use fitting template as with single-leaf version. Fastening 2x Slimdrive EMD Invers with intermediate mounting plate Fastening 2x Slimdrive EMD Invers with continuous mounting plate See above for missing dimensions...
  • Page 25 Slimdrive EMD Invers Preparing installation Direct fastening 2x Slimdrive EMD Invers Concealed line- feed for low-voltage connection: sensors, electric Active leaf strike, programme switch and lock switch contact Passive leaf Dimensional reference centre of hinge Door leaf width Concealed cable guide for mains connection 230 V / 50 Hz...

  • Page 26: Door Leaf Installation Hinge Side With Roller Guide Rail (Double Leaf)

    Door leaf installation hinge side with roller guide rail (double leaf) For vertical clearance measurement see chapter 7.2.4. Use fitting template as with single-leaf version. Fastening 2x Slimdrive EMD Invers with mounting plate Direct fastening 2x Slimdrive EMD Invers Concealed line- feed for low-voltage connection: sensors, electric...

  • Page 27: Installation

    Slimdrive EMD Invers Installation Installation 8. 1 Fitting mounting plate (option) If appropriate, screw the mounting plate (1) on using at least two screws per row of holes. Exchanging the side panel for split or continuous cover (option) Loosen 2 screws (1) as far as necessary until the side panel (2) can be removed.

  • Page 28: Cable Guide Via Door Transmission Cable For Door Leaf Installation (Option)

    Installation Slimdrive EMD Invers Cable guide via door transmission cable for door leaf installation (option) Remove the side panel (see chapter 8.2). Break out the drill hole (1) for the cable feedthrough. Push the door transmission cable (2) through the side panel (3).

  • Page 29: Installing The Drive

    Slimdrive EMD Invers Installation Installing the drive During drive installation, ensure that the power supply cables are not pinched. With mounting plate Direct attachment Screw the drive on using the recommended screw material, see chapter 7.2. Mounting the roller guide rail...

  • Page 30: Mounting The Roller Lever (For Installation With Roller Guide Rail)

    Also heed the marking on the roller lever Table applies for door opening angle TÖW of 100° for transom installation hinge side roller guide rail and tran- som installation opposite hinge side roller guide rail. Ask GEZE GmbH about suitable levers for larger door opening angles.

  • Page 31: Transom Installation Hinge Side With Roller Guide Rail

    Slimdrive EMD Invers Installation 8.6.2 Transom installation hinge side with roller guide rail Open the door (4). Attach the lever (1) as shown with the dashed line. Screw in the Allen screw (2), tightening torque = approx. 15 Nm Pre-load the lever (1) and insert it into the roller guide rail (5), closing the door at the same time.

  • Page 32: Door Leaf Installation Hinge Side With Roller Guide Rail

    Installation Slimdrive EMD Invers 8.6.4 Door leaf installation hinge side with roller guide rail à Ensure that the correct lever DIN right or DIN left is installed, conforming to the order. See stamp on the roller lever. à If the frame makes installing the lever difficult: Mount the roller lever on the drive before the drive is installed.

  • Page 33: Link Arm

    Slimdrive EMD Invers Installation Link arm 8.7. 1 Install the link arm bearing block Screw the link arm bearing block (1) on with 2 screws. 8.7.2 Mounting the link arm Observe the instructions in the link arm packaging. For the installation dimensions, see chapter 7.2.3.

  • Page 34: Dismantling The Link Arm

    Installation Slimdrive EMD Invers Set the marking (4) for how far the inner shank (6) has to be pushed into the outer shank (5). Install the drive-side lever (7) on the drive shaft and attach as marked. Install the door-side lever (5) on the door.

  • Page 35: Mounting The Shaft Covers

    Make sure that no cables become jammed. Lay the cover earthing cable in such a way that it is not near moving parts. Clip on the GEZE logo (1) in a suita- ble position on the cover and turn by 180°...

  • Page 36: Electrical Connection

    Electrical connection Slimdrive EMD Invers Electrical connection 9. 1 Mains connection WARNING! Risk of fatal injury due to electric shock! Get a qualified electrician to connect and disconnect the electrical system (230 V). Carry out mains connection and earth conductor test in accordance with VDE 0100 Part 610.

  • Page 37: Settings

    Slimdrive EMD Invers Settings Settings 10. 1 Setting the opening torque A hook wrench size 20-22 mm is required for setting. à For commissioning, it is recommended to set the spring pre-load to marking 1. Set the opening torque at the power storage device in such a way that the door opens securely.

  • Page 38: Opening Speed In De-Energised State

    Settings Slimdrive EMD Invers 10.2 Opening speed in de-energised state This special case occurs in the event of a power failure or fire alarm or when the drive is switched off electrically. The opening speed is electrically controlled in this operating status too.
  • Page 39 Slimdrive EMD Invers Settings Drive type (first character) Swing door drive (classified in the factory) Durability of the drive (second character) 500,000 test cycles, with at least 1,200 cycles/day (classified in the factory) Type of door design (third character) Swing door (classification factory provided)

  • Page 40: Commissioning Tests

    Electrical brake in de-energised state The Slimdrive EMD Invers has a brake which is controlled electrically for the opening speed. This is operable during a power failure, with an electrically deactivated device and in the case of a fire alarm...

  • Page 41: Maintenance Work

    Let the motor cool down. 13.2 Maintenance work The Slimdrive EMD Invers is maintenance-free to a great extent and no extensive work has to be carried out with the exception of that specified below: Check the roller lever or the link arm for damage, replace if necessary.

  • Page 42: Electrical Faults

    – Peripheral cables connected? – – All cables secured? – – Slimdrive EMD Invers put into operation with ST220, GEZEconnects or – – DPS (see wiring diagram)? Cover attached? Protective earth conductor connected? – – Door stop buffer or opening restrictor installed?
  • Page 43 Slimdrive EMD Invers...
